Product Description

1.Full complement cylindrical roller bearings with snap ring grooves
2.SL045010PP=NNF5010 ADA-2LSV
3.d:45mm D: 75mm B:40mm

Full complement cylindrical roller bearing with snap ring grooves
Designation	Designation	MASS	Dimensions				basic load ratings
ASAL.REF	SKF.REF	KG	d(mm)	D(mm)	B(mm)	C(mm)	DYN.(KN)	STAT.(KN)
SL045010PP	NNF5010-ADA-2LSV	0.76	50	80	40	39	97	142
SL045011PP	NNF5011-ADA-2LSV	1.18	55	90	46	45	115	175
SL045012PP	NNF5012-ADA-2LSV	1.26	60	95	46	45	120	189
SL045013PP	NNF5013-ADA-2LSV	1.33	65	100	46	45	125	203
SL045014PP	NNF5014-ADA-2LSV	1.87	70	110	54	53	168	265
SL045015PP	NNF5015-ADA-2LSV	1.96	75	115	54	53	194	300

Feature:

Cylindrical roller bearings with snap ring grooves are full complement,double row units comprising solid outer and inner rings with ribs,rib-guided cylindrical rollers and sealing rings.
The outer rings have grooves for retaining rings.
The inner rings 1mm wider than the outer rings and held together by a rolled-in steel strip.
The bearings are available as a light series SL04..-PP and in the dimension series 50 as sl0450..-PP.
Bearings for cable sheaves
Due to the gooves in the outer rings,the bearing rings can easily be axially located. The bearings are therefore highly suitable for cable sheave bearing arrangements.
Sealing&lubricant
Sealing rings on both sides protect the running system against contamination and moisture.
The cylindrical roller bearings are greased with a lithium complex soap grease and can be relubricated via the outer and inner ring.
