Hologram Master Recombining Machine
Main Parameters:
|
Model |
YXZB-650 |
|
Effective recombination area |
1000mm*650mm |
|
Recombination precision |
0.01mm |
|
Maximum pressure |
15MPa |
|
Walking way |
Matrix, dislocation, tilt, coordinate Automatically controlled, Windows user interface |
|
Weight |
1.8tons |
|
Dimension (L/W/H) |
1.45/2.3/1.9m |
|
Other model of our combining system |
Model a: YXZB-400 Model b: YXZB-950 |
Functions
To recombine small master into big master shim. This machine has small floor space, the recombination master is large in size. The computer automatically control, can recombine different shape on the same plate. The recombination is high in precision.
Overall view:
Components view
*******************************************************************************
We are a Chinese professional Company in producing hologram security products to protect your brand and commodities. We have succeeded in supplying hologram overlay for Olympic Games and Asian Games.Bellow is our main products:
1. Supply hologram related product such as: hologram security label/sticker, hologram tape, hologram package, hologram overlay/pouch hologram metal label etc.
2. Produce hologram master. Our hologram master not only have good brightness, but also have all the features like Multi channel effect, Kinetic effect and Guilloche Pattern,2D/3D,Switch effect, Laser Readable Image, Gradient effect, Micro text, Lens effect, relief effect, True color image, Full 3D,White effect etc. The size range is within 800mm X 1200mm.
3. Provide hologram related machines like hologram dot matrix machine, recombining machine, electroforming system, embossing machine, glue spreading system, Automatic die-cutting machine. And more important, we can produce these equipments and machines according to our clients` requests.
*******************************************************************************
