Linear motor, its structure is very simple. It has a wide range of applications and can meet customers' requirements for automatic application upgrades.For example, Ic packages, photovoltaic solar energy, 3C electronics and other automatic production equipment can be used. In order to meet the specific application requirements, the selection of a linear motor must consider many aspects, such as speed, accuracy, thrust, environmental factors, etc. The fastest and most reliable way to determine these requirements is to use the linear motor selection tool for operation. There are a large number of parameters in the database for selection and matching. The selection tool will provide the best solution and customers can choose according to their needs.

Linear motors are also known as direct drive linear motors.The steady growth in practical industrial applications proves that linear motors can be used safely. The following is a brief introduction to the types of linear motors and how they differ from rotating motors. The most commonly used types are flat, U-slot and tubular. The typical composition of the coil is three-phase, with a Hall element to achieve brushless commutation.

How Non Magnetic Track linear motor works?

About our MTF Linear Motors working principle, the most basic electromagnetic theory is still unchanged, but it adopts the latest magnetic field modulation theory, self-modulated ferroalloy stator. We transfer the magnet supposed to be laid on the stator to the mover, so that the coil and magnet are integrated on the mover.The synonym-shaped design on the stator provides a magnetic circuit that essentially interacts with two magnetic fields to generate thrust

When the mover moves, the corresponding magnet also moves with it. That is, the activist will have an excitation magnet with a movement, magnet movement to which part, which part produces electromagnetic force. Thus, like the rotating permanent magnet synchronous motor, the magnet utilization rate reaches 100%, and no extra magnets are exposed. The design of this structure overcomes two shortcomings of conventional linear motors.Namely, the large amount of magnets and the low utilization rate. This greatly reduces the cost of linear motors and improves safety.

Linear motor actuator application:

Ic Package,Testing Of Semiconductor Equipments
Ic Patching,Photovoltaic Panel Manufacturing
Laser Cutting Equipments,
Medical Apparatus And Instruments,Machine Tools,Optical Equipments,Display Panel Manufacturing.

Features and Performance

Product categories of advanced Linear Motor Module,as the professional linear motor and encoder manufacturer from China,we provide competitive linear motor modules.Self-developed new technology magnetic track free linear motor.Manufacturing and wholesale high quality Single Axis Robots.ALM has the perfect after-sales service and technical support. Look forward to your cooperation!
