600mm WPC wall panel plastic extrusion

600mm WPC wall panel plastic extrusion

FEATURES OF PVC WALL PANEL PRODUCTION LINE

 1. PVC wall panel extrusion line adopts exclusively designed conical twin screw extruder, with vacuum degassing system, can get rid of the waste gas from the raw material which can ensure good quality of final granules;

 2. Gearbox: from Jiangyin Deling gearbox company, very famous brand in China, with nice outline, stable running, low noise and long service time;

 3. Driving system: adopting Siemens motor, which provide stable torque output and various speed;

 4. ABB frequency converter and Schneider electric control system which have wide adjustment range, high precision temperature control, simple operation and good reliability;

 5. The production line is equipped with large forcing cooling device to ensure good effects of the PVC profile for wall panel;

 6. Caterpillar-type haul-off unit utilizes branded reducing speed motor and ABB frequency inverter, and is featured in reasonable structure design, large and stable hauling power.

PRODUCT DESCRIPTION

1. We are expert manufacturer of PVC wall panel making machine and can supply you turnkey solution including supplying machines, installation, training staff, material purchasing help, help send Chinese production master etc.

2. We can show you running PVC wall panel production line in our factory and our customer's factory.

3. The most important thing is that we have manufacturing PVC Profile for wall panel for over 20 years, we are familiar with all production process and we know how to make machines perfect and how to reduce production cost.

THE COMPLETE EXTRUSION CONSISTS OF FOLLOWING ITEMS:

· Conical Twin Screw Extruder:

· It is used for melting and stirring plastic material. LANGBO adapts special screw and barrel type that provide perfect mixing and homogenous. We use special gear box for the Extruder which has axial bearings. Transfer the motor to the screw. For minimizing electricity consumption, we use the famous brand of driving motor of “SIEMENS” on our Extruder. Automation system designed with PLC and touch panel controller can be selected.

·

· Mould:

· Our mould designing gives ideal viscosity to melt material for profile producing. It gives profile or shape to plastic after processing. All faces the plastic in contact with is polish, so that frication losses minimized.

· Calibration Table:

· The shaped profile that come from mould is subjected to calibration and cooling processing on the calibration table. The designing of calibration table varies according to the type and characteristic of the profile. The area that contacts with water is made of stainless steel in order to prevent corrosion.

· Caterpillar Haul-off:

· The designing of caterpillar haul-off changes depending on the contact area that is related to the profile measurement. The inverter control is standard on all caterpillar haul-off. For this reason, as the speed can adjusted with respect to material output rate. The caterpillar haul-off is also capable of making measurement adjustment through speed control equipment.

· Saw cutter:

· In the speedy working condition, profile saw works with high efficiency in term of cutting frequency. As the saw table and clamps move synchronously. The saw cuts the profile in required length.

· During the cutting processing, swarf and dust appears, in order to prevent these in production area, there is a dust collection unit is integrated in saw cutter. This unit absorbs swarf, dust effectively and removes to storage.

· Tip-off unit:

· It operates on pneumatic cylinder.

The Table provides a general information for standard Product.

For Further customized technical assignment please contact us.
