Automotive Checking Standard Components

According to the positioning needs, it is divided into the main and deputy positioning pins, the main positioning pins are cylindrical, and the deputy positioning pins decide to use round or diamond pins according to the shape of the product's deputy positioning holes, and the diamond guide pin set must be set as anti-rotation structure.  The diameters of the main and auxiliary positioning pins are: aperture size-position tolerance, manufacturing tolerance 0/-0.02mm.  The check pin is used to detect the position of the detection hole. According to the detection position, it can be divided into two types: cylindrical pin and marking pin. For ansteckdose, It consists of Plastics and PU Steel Wire. For expansion suit on gauge, It is made up of cast steel and sup.

Technical Parameter

1. No chamfering C0.5, deburred

2. No tolernace of +/-0.3mm

Details Of telescoping drive

Part Number: 49-HD-TJ-A

Part Number: 49-HD-TJ-B

Part Number: 49-SSDZ-A

Part Number: 49-HD-SSDZ-B

Part Number: 49-HD-SSTZ-A

Part Number: 49-HD-SSTZ-B

E-Catalogue Of  Hongyi Tengda Automotive Checking Accessories

Hot Selling Products

Our Factory and Quality Management

Currently We have 3 CNC high speed machining machines, 6 Punch Machines, 8 Grinding Machines, CMM Inspection, Projector, Digital Caliper etc. We have Production department, Quality Control department, Packaging Department, Sales and Design department, we have formed a standard work flow.
