BT40 Ridgid Right Angle Drill

Get Latest Price

Transportation:: Ocean, Land, Air, Express

Port:: Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	T/T
Incoterm:	FOB,CIF,EXW,CFR,Express Delivery
Transportation:	Ocean,Land,Air,Express
Port:	Shanghai

Product Description

Installation of Angle Head

Before use, please apply oil on the input shaft and the output shaft to prevent the accuracy error caused by the accelerated corrosion of temperature rise. After use wipe it clean and oil the input and output shafts for maintenance.

In case of diffiffifficulty in rotating the input / output shaft, excessive noise, collision and other abnormal condit--ions, please contact our company or our contact the distributor.

Butter: PENNZOIL No.362

How to add to the angle head: use S1000 to drive the angle head 3 times with a grease gun. If it is necessary to tap M4 and tool diameter φ For milling cutters above 6, the collet nut needs to apply greater locking force.

The cutter length of the milling cutter shall not be too long, and proper rotation speed and feed, otherwise the cutter will be severely shaken. he machining shall be matched with the

If the side angle head is damaged and cannot be used, please ask the dealers first. Do not try to repair it by yourself.

Parameter:

PRM----Highest 4000RPM Torsion-----8N.M

Raw Material: Japan Imported Gear/Bearing Germany INA Oil Seal

Clamp Range: 1-6mm Thread: Biggest M4(S45C)

Gear Ratio: 1:1.44

Material: Steel

Inspection: 100% Inspection before shipping to ensure the quality

Model no: BT40-GXD6-263

angle head cat 40
