Water Reuse System Equipment

Product Description

Reverse Osmosis Equipment

1. Brief introduction of Reverse Osmosis Equipment For Water Reuse:

       Industrial Water Treatment Systems offers that non-drinking water transfers to certain water quality standard. Reclaimed water mainly refers to non-drinking miscellaneous water that can be reused within a certain range after treatment of urban sewage or domestic sewage to a certain water quality standard. The water quality is between the upper water and the sewage, and it is a water resource. Equipment For Use In Water is A form of effective way.
       Reclaimed water in buildings refers to the treated and reused miscellaneous water systems in buildings or groups of buildings.
       Residential reclaimed water, a reclaimed water system established in the building community.
       Miscellaneous drainage, all kinds of drainage in civil buildings except fecal sewage.
       Reclaimed water source refers to water that has not been treated as a source of reclaimed water. The source of water in a building can be domestic drainage and other available water sources.
       Reclaimed water reuse system refers to a water supply system that uses various drainage such as domestic drainage, cooling water and rainwater after use in civil buildings or residential quarters to be reused in buildings or residential quarters after proper treatment as a miscellaneous water supply system. Miscellaneous water is mainly used for flushing toilets, washing cars, greening and washing roads.
       Setting up reclaimed water can not only effectively use and save limited and precious fresh water resources, but also reduce pollution and wastewater discharge, reduce water environmental pollution, and alleviate the overload of urban sewers. It has obvious social, environmental and economic benefits.

2. Design process of reclaimed water reuse system:
      Under normal circumstances, there are the following 3 processes for selection:
      1. Select membrane + activated carbon process Raw water—grid—regulating tank—membrane treatment—activated carbon—disinfection
      2. For the process of high-quality miscellaneous drainage and miscellaneous drainage as the source of intermediate water, physical and chemical treatment is the main raw water-grille-regulating tank-coagulation or air flotation-filtration-disinfection, focusing on physical and chemical + membrane method raw water-grille -Regulating tank-coagulation-membrane treatment-disinfection.


 3. The process of miscellaneous drainage and mixed sewage as the source of reclaimed water, with biochemical treatment as the main raw water—grid—regulating tank—biological treatment—sedimentation—filtration—disinfection—using two-stage biochemical process raw water—grid—regulating tank— One-stage precipitation-two-stage precipitation-filtration-disinfection.
Three, the main advantages of water reuse system equipment:
    1. Circuit board, electroplating, textile printing and dyeing, 65%-85% recycling in power plant;
    2. Discharged water can pass the first-level and second-level discharge standards stipulated by environmental protection;
    3. Make the process water have more stable and better water quality;
    4. The recovered water quality is stable below 100us/cm.
    5. Lower operating costs (water costs, environmental maintenance costs are reduced);
    6. Save a lot of water bills and optimize environmental resources;
    7. It has good economic benefits, and the initial investment cost can be recovered within 1-2 years;
    8. When water is limited or lacking in the industrial zone, the normal production of the factory can be guaranteed;
    9. There is no need to increase emissions or water supply when expanding production;
    10. Fully automatic continuous or mechanical operation is suitable for large-flow wastewater recycling;
    11. The recovered water can be supplied to the pure water system or directly reused in the production line;
    12. The system has a long service life, low failure rate and easy maintenance.
