EDI Integrated Pure Water Equipment Treatment

Product Description

Product details: EDI integration is a new desalination process that combines electrodialysis and ion exchange. This technology uses the electric regeneration ion exchange desalination process to replace the traditional mixed ion exchange desalination process DI. High desalination effect is achieved through ion exchange resin and selective ion membrane. The combined process combined with reverse osmosis enables the water quality to reach a high desalination effect of 10~15MΩ. EDI adopts standard component design and can be combined into different specification systems according to requirements. Working principle: EDI pure water equipment is a pure water manufacturing technology that combines ion exchange technology, ion exchange membrane technology and ion electromigration technology. It cleverly combines electrodialysis and ion exchange technology, and uses high voltage at both ends of the electrode to make Charged ions move in water, and cooperate with ion exchange resin and selective resin membrane to accelerate ion movement and removal, so as to achieve the purpose of water purification. In the process of EDI desalination, ions are removed through the ion exchange membrane under the action of electric field and water molecules are in the electric field. Under the action, hydrogen ions and hydroxide ions are generated. These ions continuously regenerate the ion exchange resin to keep the ion exchange resin in the best condition. The EDI device membrane stack is composed of a certain number of units sandwiched between two electrodes. There are two different types of chambers in each unit: the fresh water chamber to be demineralized and the concentrated water chamber to collect the removed impurity ions. The fresh water compartment is filled with mixed cation and anion exchange resins. These resins are located between two membranes: a cation exchange membrane that only allows cations to pass through and an anion exchange membrane that only allows anions to pass through.
