Basic Info

Product Description

Insulation: High vacuum multilayer insulation.

Storage Medium: LOX, LIN, LAr, LCO2, LNG, etc.

Volume：1-7.5m³

Working pressure：up to 3.5Mpa

Microbulk tanks have a very similar structure with vacuum insulated storage tanks, comprising double layers/shells (stainless steel & carbon steel), vacuum insulation, storing the gas in liquid form at very low temperature under low pressure, and suitable for multiple types of gases. Meanwhile, microbulk systems integrate a small ambient vaporizer to enable the output of gas directly.

Specification
Volume(m³)	2m³	3m³	5m³	7.5m³
Working	0.8/1.6/2.1Mpa
Filling Medium	LNG,LO2,LN2,LAr,LCO2
Usable Volume(m³)	2	3	4.8	7.3
Container	Inner Container Material S30408 /Outer Container Material Q345R
Device Size(LWH mm)	18431960 2340	18431960 3090	22432360 3130	31702715 2450
Tare Weight(KG)	1264	1743	2802	4029
