CGF16-12-6 Automatic liquid filling machine (Monobloc filling machine 3-in-1)
- Payment Type:
- T/T
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 30 Days
- Transportation:
- Ocean
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China Longway |
|---|---|
| Productivity: | 2000-20000 |
| Supply Ability: | 10set |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Certificate: | CE |
| Transportation: | Ocean |
Product Description
Product Description
CGF Series Full-Automatic Washing, Filling and Capping 3 in 1 Machines.
This series of machines are used for packing the pure water, mineral water, juice, etc. By PET bottles.
The washing, filling and capping 3 kinds of jobs will be finished just by this one machine. It is very convenient to change diverse sizes of bottles by means of advanced bottle conveying technology--bottleneck clamping & bottle suspending technology. Advanced programmable PLC is equipped to control the main machine. Main electronic components are all from famous international enterprises. All spare parts that may touch with water are made from high-quality stainless steel.
| Model: | CGF16/12/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 | CGF40/40/12 | CGF48/48/12 |
| Production Capacity:500ml(B/h) | 4000 | 6000 | 10000 | 14000 | 17000 | 20000 |
| Suitable Bottle Standard:(mm) | 150-300 | 150-340 | 150-340 | 150-340 | 150-340 | 150-340 |
| Suitable Cap Standard:(mm) | φ50-φ110 | |||||
| Filling Pressure:(Mpa) | 0.2-0.3 | |||||
| Installed Capacity:(L) | 3.13 | 3.84 | 3.84 | 5.6 | 6.3 | 7.3 |
| Filling Temperature: | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature |
| Overall SizeL×W×H(mm) |
2400×1670 ×2350 |
2470×1970 ×2350 |
2865×2170 ×2350 |
3700×2570 ×2350 |
3800×2950 ×2400 |
4500×3400 ×2400 |
| Total Weight:(kg) | 2500 | 3000 | 4000 | 5000 | 6000 | 7000 |
