PVC corrugated roof tile extrusion line

$25000.00 - $65000.00/Set/Sets

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Transportation:: Ocean, Land, Air

Port:: SHANGHAI, NINGBO, TIANJIN

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	400KG/H
Supply Ability:	70SETS/YEAR
Payment Type:	L/C,T/T,D/P
Incoterm:	FOB,CFR,CIF,EXW
HS Code:	84772090
Transportation:	Ocean,Land,Air
Port:	SHANGHAI,NINGBO,TIANJIN

Product Description

Machine features of PVC corrugated roof tile extrusion line:

Adopt PLC control and simple operation.

Adopt Electric-magnetic heater which can save 40% -60% electric power for customer.

All Electric Part (breaker/motor/relay /Inverter and so on) is Siemens/Schneider/Omron

Material of screw and barrel: 38CrMoAlA, nitrogen quenched which the thickness layer 0.4-0.7mm; Hardness of screw barrel: >940 HV;

Comprehensive plasticizing element, ensure the plasticizing effects of materials.

Technical parameters:

Product width(mm)	Product thickness(mm)	Extruder	Max. output(kg/h)	Total Length
880mm	2-4mm	SJSZ-80/156 FSJ-45/28	390kg/h	customizing
1040mm	2-4mm	SJSZ-80/156 FSJ-50/28	420kg/h	customizing

Product application:

The Glazed Tiles are widely used in the garden style factory, tourist scenic spots, pavilions, hotels, family building. etc. it is one kind machine of Plastic Board Sheet Extrusion Machine, in plastic extruder industry, we also can supply Plastic Pipe Making Machine,Plastic Profile Extrusion Machine, Plastic Board Sheet Extrusion Machine as well as some Plastic Auxiliary Machinery.
