Elevator infrared photoelectric light switch sensor

Elevator infrared photoelectric light switch sensor

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Transportation:: Express, Ocean, Land, Air

Port:: Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	10000PCS/MONTH
Supply Ability:	500000 Piece/Pieces per Year
Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Certificate:	ISO, CE
HS Code:	8431310001
Transportation:	Express,Ocean,Land,Air
Port:	Shanghai

Product Description

Elevator infrared photoelectric light switch sensor

A photoelectric sensor is a device used to determine the distance, absence, or presence of an object by using a light transmitter, often infrared, and a photoelectric receiver. They are largely used in industrial manufacturing. There are three different useful types: opposed (through-beam), retro-reflective, and proximity-sensing (diffused).

Electric Components

·Elevator Cabin includes
Complete Elevator Cabin, Car Frame, Counterweight Frame and Counterweight Block,Guide Shoes, Rope Attachment etc.
·Door System includes
Mitsubishi, Fermator and Selcom Door Operator and Landing Door, BST Door System, Wittur Door System, Door Panel, Door Spare Parts,Safety Light Curtain/Photocell etc.
·Safety Components includes
Safety Gear, Speed Governor, Rope Brake, Oil Buffer and Rubber Buffer etc.
·Traction System includes
Geared Traction Machine/Gearless Traction Machine, Pulley Sheave,Anti-Vibration Pad,Steel Wire Rope etc.
·Shaft Components includes
Machined /Cold Drawn/ Hollow Guide Rail, Fishplate, Fasteners, Anchor Bolt, Rail Rracket etc.
·Electrical Components inclueds
Integrated and Separated Controlling Cabinet,Yaskawa L1000A Inverter, Elevator Display,Elevator COP&LOP&HOP, Elevator Button, Flat Traveling Cable etc.

Product Paramenters

Supply Voltage	DC12V - 30V
Power Consumption	≤40mA
Detection Method	Opposite
Detection Distance	30mm
Detection Channel	Single Channel
Response Frequency	＜1ms
Control Output	Negative voltage Max:30V, Single-channel Drive Current Max:100mA, Residual Voltage Max:0.6V
Withstand Voltage	500VAC 50/60Hz 1min
Light Limit	Incandescent Lamp：≤400Lux, Sunshine:＜100000Lux
Ambient Temperature	Working Status:-25℃ - 75℃, Storage Status:-30℃ - 80℃
Environmental Humidity	Working Status:35 - 80%RH, Storage Status:35 - 80%RH
Protection Level	IP54
Material	Inconel
Weight	150g
