Product Description

High Quality Hospital Lift Size, China Manufacturer Hospital Elevator Size

The elevator can be customized according to the actual site size and customer needs.
Cabin finish: painten steel,stainless steel,glass
Hall call: Dot matrix,LCD
Load capacity: 400kg,450kg,630kg,800kg,1000kg,1150kg,1350kg,1600kg,2000kg
Control system: VVVF
Car ceiling: S.S with LED down light
Speed: 1.0m/s,1.75m/s,2.0m/s,2.5m/s

Car floor: PVC,Marble/Granite(optional)

Specification

Capacity	Speed	Cabin		Net opening size		Opening Way	Shaft		Overhead Height	Pit Depth
Capacity	Speed	CW	CD	JJ	HH	Opening Way	HW	HD	OH	PH
1000	0.5/1	1400	1700	1400	2100	2 Panels Side opening	2500	2200	4200	1400
1600	0.5	1500	2300	1500	2100		2650	2800
2000	0.5	1800	2300	1500	2100		2650	2800
3000	0.25/0.5	2000	2800	2000	2100	4 Panels Center Opening	3400	3300
4000	0.25/0.5	2200	3300	2000	2100		3750	3800	4500	1500
5000	0.25/0.5	2400	3600	2000	2100		4100	4100	4500	1500

High Quality Hospital Lift Size, China Manufacturer Hospital Elevator Size

Electric Components

·Elevator Cabin includes
Complete Elevator Cabin, Car Frame, Counterweight Frame and Counterweight Block,Guide Shoes, Rope Attachment etc.
·Door System includes
Mitsubishi, Fermator and Selcom Door Operator and Landing Door, BST Door System, Wittur Door System, Door Panel, Door Spare Parts,Safety Light Curtain/Photocell etc.
·Safety Components includes
Safety Gear, Speed Governor, Rope Brake, Oil Buffer and Rubber Buffer etc.
·Traction System includes
Geared Traction Machine/Gearless Traction Machine, Pulley Sheave,Anti-Vibration Pad,Steel Wire Rope etc.
·Shaft Components includes
Machined /Cold Drawn/ Hollow Guide Rail, Fishplate, Fasteners, Anchor Bolt, Rail Rracket etc.
·Electrical Components inclueds
Integrated and Separated Controlling Cabinet,Yaskawa L1000A Inverter, Elevator Display,Elevator COP&LOP&HOP, Elevator Button, Flat Traveling Cable etc.
