COMPASS jeep 12 volt electric winch
-
$270.0050-499 Piece/Pieces
-
$245.00≥500 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Supply Ability: | 1000 Piece/Pieces per Week |
|---|---|
| Payment Type: | L/C,D/P,D/A,T/T,MoneyGram |
| Incoterm: | FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DDP,DEQ,DDU,Express Delivery,DAF,DES |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shanghai |
Jeep 12 volt electric winch
Our factory offers all kinds of 4 wd winches and truck winch. This 15500 Lbs winch has excellent reliability and value. The low-profile designallows multiple installation options, making it ideal for most trucks, jeeps and SUVs. This is a compact, efficient and robust kit. It has a powerful tension series winding motor. The installation is simple, multi-station installation and rapid displacement can be realized, and it has the advantages of small size, large reduction ratio and long service life. Car winch 12v is the perfect partner to overcome various complex terrains in the field. Our plant offers various 4 wd winches and truck winch with lower amp draw at a price that is extremely competitive.
|
Manufacturer Part Number:
|
D265224-15000AS
|
|
Brand:
|
DAO
|
|
Certification
|
CE
|
|
Drum Size:
|
Diameter 2.52" × Lenght8.82" (64mm × 224mm)
|
|
Cable:
|
79ft of 3/8"± diameter（24m of 9.5mm diameter）
|
|
Overall Dimensions:
|
（L×W×H）25.2"×14.6"×10.2"（640mm × 370mm × 260mm）
|
|
Recommended Battery:
|
650CCA Minimum for Winching
|
|
Battery Leader:
|
2 gauge,72"(1.83m)
|
|
Motor:
|
8.84HP/6.5KW, series wound
|
|
Finish:
|
Black
|
|
Control:
|
Remote switch,12ft(3.7m)lead
|
|
Gear Train:
|
3 Stage planetary
|
|
G.W:
|
30KG
|
|
Gear Ratio:
|
370/1
|
|
Mounting Bolt Pattern:
|
10.00±0.015" × 4.50±0.010" (254mm × 114.3mm)
|
|
Clutch:
|
Sliding Ring Gear
|
|
Remote Control:
|
Include
|
|
Brake:
|
Mechanical brake
|
|
Performance:
|
12VDC
|
|
Fairlead:
|
Aluminum Fairlead
|
|
Rated Line Pull:
|
15000LBS
|
Features:
1. Free spooling clutch
2. Automatic screw cone braking action
3. DC 12V or DC 24V Power drive optional
4. Series Wound Motor
5. Remote control through control box and switch
6. Wireless remote control available F type fixed in control box
