New Color Wire Rope Winch
The electric winch is replaced with a stronger black frosted shell and equipped with Waterproof IP67 rating and state-of-the-art 500AMP solenoid valve. With updated braking system, the 12000 Lbs winch is more insulated and durable, avoiding the problem of clutch damage or motor burning. The wireless remote control expand the range of transmission signal. You can operate the 4x4 winch in a precarious situation away from the vehicle with the wireless remote control, and stay away from certain risks as well.
12000 Lbs Electric Winch Specifications
- Motor: 8.84HP/6.5KW, series wound
- Drum Size: 64mm × 224mm
- Cable: 24m of 9.5mm diameter
- Overall Dimensions: 640mm × 370mm × 260mm
- Recommended Battery: 650CCA Minimum for Winching
- Gear Train: 3 Stage planetary
- Gear Ratio: 265/1
- Mounting Bolt Pattern: 254mm × 114.3mm
- Brake: Mechanical brake
Features:
1. Free spooling clutch
2. Automatic screw cone braking action
3. DC 12V or DC 24V Power drive optional
4. Series Wound Motor
5. Remote control through control box and switch
6. Wireless remote control available F type fixed in control box
