Improved type Ⅱ rail fastening system Russia standard

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Transportation:: Ocean, Land, Air, Express

Port:: Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Supply Ability:	1800000 Tons
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,EXW,FCA,CIP,DDU,Express Delivery
Transportation:	Ocean,Land,Air,Express
Port:	Shanghai

Product Description

Improved type Ⅱ rail fastening was improved from chemical anchor bolt to plastic insert anchor type, it is mostly used in China or Russia standard rail like 60kg/m or p43, 50kg or R50, with ballast track,concrete sleeper with shoulder block. The main advantage is easy to replace and maintenance, cost economic.railroad, ballast or ballast less track.

Main components:

* Tension clamp China type Ⅱ --2pcs

*Steel guide plates--2pcs

* Insulator--2pcs

* Rail pad--1pc

*Plastic insert dowels--2pc

*Double lead anchor bolt--2pc

*Hex Nuts--2pc

*Flat washers--2pc

Components description:

W type Rail elastic clip/ SKL clip

Raw material: 60Si2CrA, 38Si7,60SI2MN
Type:China type Ⅱ
Surface: plain ( oil), black paint, color paint, etc

Rail pad
Raw material: Rubber
Surface: plain

Insulator
Raw material:PA66+30%GF

Surface: plain

Steel guide plates

Raw material:PA66+30%GF

Surface: plain

Flat washer
Size: TB/T1495.4
Raw material: Q235,45#
Surface: black, zinc, hdg

Double lead anchor bolt

Grade: 4.6, 5.6, 8.8
Raw material: Q235, 35K, 45#, 40Mn2, 20MnSi,

Surface: plain (oil), black, zinc, hdg, etc

Hex nut

Grade: 5, 6,8
Raw material: Q235, 35K, 45#,

Surface: plain (oil), black, zinc, hdg, etc

Plastic insert dowel

Raw material:PA6, PA66, HDPE

Surface: plain

Reference Project:

Vietnam

Our products are performing widely in more than 50 countries in the world, for exporting, there are mainly divided four areas as below:

America mainly in USA and, Canada, Mexico and Brazil:
We supply E type rail fastening, W14 rail fastening systems, rail clips to metro, tramway fastenings, crane rail clips, track bolts and joint bar for rail connection, screw spikes, tie plates and concrete rings connection bolts for tunnels. They are mainly according to standards of AREMA, IFI, ASTM, UIC and other specifications from clients.

West Europe and Africa areas mainly in Spain, German, South Africa and Nigeria:
We supply W rail fastening systems, spring blade fastening systems, KP fastening system, metro rail fastenings,fish plates and fish plate bolts, sleeper screws, lock spikes, spear bolts for tunnels etc. They are manufactured to standard of UIC, NF ,DIN, BS and other specifications requested by clients.

East Europe and Mid-Asia area mainly in Russia, Kazakhstan, we supply:
W rail fastening systems, KP fastening system, rail joint bars and track bolts, track spikes and tie plates to this area. We manufacture and supply according to standard GOST, UIC, DIN and other specifications requested by clients.

Australia and Southeast Asia area mainly in Australia, Thailand, we supply:
E type rail fastening, W rail fastening, heavy haul rail fastenings, metro rail fastenings,fishplate and bolts, track spikes, turnout accessories, concrete ring connection bolts etc. We manufacture and supply according to standard BS, AS, JIS, UIC and specifications requested by clients.

Testing facilities

testing machine-1 testing machine-2 testing machine-3
