Product Description

ES430-CAT.M is a 4G (CAT-M) waterproof GPS asset tracker. Carefully designed for long battery life, it can last 2 year under one report per day mode with 2500mAh battery. Embedded with magnets, this asset GPS tracker can easily attach to vehicle, trailer, container for asset tracking. ES430-CAT.M will automatically switch to cell-ID based location reporting whenever GPS is not available.

GPS mini tracker asset gps tracker

Physical and Electrical

Dimensions: 80mm*50mm*23mm

Weight: <130g

Rechargeable Battery capacity:

1000/2500 mAh

Power Consumption:

-Active mode:< 78 mA 3.8VDC

-Sleep mode:<4 mA 3.8VDC

-Deep Sleep Mode:< 60 uA 3.8VDC

Operation temperature: -20℃ to 65℃

Storage temperature (Without battery):

-40℃ to 85℃

Charging mode: USB charging

Built-in Cellular and GPS antenna

Module: BG96 from Quectel

Chipset Type: MDM9206 from Qualcomm

GPS Specification

-162 dBm Tracking Sensitivity

Accuracy (Open Sky): <2 m (CEP50)

Cellular Communication

Cat.M1 & NB1:

LTE-FDD: B1/B2/B3/B4/B5/B8/

B12/B13/B18/B19/B20/B25/B26/B28

LTE-TDD: B39 (for Cat.M1 only)

Output Power: 23dBm±2.7dBm

GSM

GSM850/GSM900/DCS1800/PCS1900

Output Power:

GSM850/900: 33dBm±2dBm

DCS1800/PCS1900: 30dBm±2dBm

Protocol: HTTP/TCP/UDP/SMS
