0804 Ball Screw with flange for medical machine
-
$15.00≥1 Others
- Min. Order:
- 1 Others
- Min. Order:
- 1 Others
Your message must be between 20 to 2000 characters
Contact Now|
Material
|
Stainless steel or GCr15 ; others available upon request
|
|
Dimension
|
Norminal Diameter : from 4 to 40mm
|
|
Thread Direction
|
Right hand thread, left hand thread, bi-directional thread all available
|
|
Accuracy Grade
|
C3 C5 C7
|
|
Application
|
Automatic controlling machines, semi-conductor industry, general industrial machinery, machine tools, medical equipment, parking systems, measuring instrument, Automatic computer strip machine, Gantry cranes, Gantry robot, 3D engraving machine etc.
|
|
|
The marked price in the page is not the authentic transaction value. Because the category of screw's products belongs to customized products, the actual price should be given corresponding discount by products' specifications and order quantity.
|
flange ballnut diameter 10mm pitch 2mm ball screw 1002
flange ballnut diameter 10mm pitch 2mm ball screw 1002
right hand and left hand ball screw, bi-directional ball screw
1. We Screwtech is a professional manufacturer of Ball Screws,Lead Screws.Meanwhile, Distributing Stepper Motor,Linear Guideway,AKD-Support for ball screw,Coupling,Linear Module for more than 10 years.
2. We are factory:We can offer you products of high quality with competitive price and fast delivery.
3. Customized service:Various models are available upon request.
4.We can produce the same size as HIWIN, TBI, PMI, and THK.
Features of our mini ball screw
※ High mechanical efficiency
※ Zero Axial play
※ Accuracy grade of C3, C5, C7
※ Long service life
※ Smooth running
1.We have business rlations with clients both domestic and abroad.
2.With the high quality,good service as well as reasonable price,
We've kept steady and large exporting to Europe, Northern America, Australia,Korea and so on.
Package Details : In cartons or Wooden cases upon your requirement
For samples:we have DHL, FEDEX VIP account, so the shipping freight will be much cheaper after discount.
For bulk order:we have freight forwarder to ship by air,by train or by sea.You can also arrange shipping through your own agent.
|
Name
|
WKT Miniature Ball Screw
|
|
Diameter
|
4mm-16mm
|
|
Lead
|
1mm-10mm
|
|
Length
|
Depending on diameter and accuracy grade, longest to 1000mm.
|
|
Material
|
GCr15(HRC60), 9Cr18(HRC 55-58 ), Stailess Steel
|
|
Accuracy Grade
|
C3,C5,C7, backlash from 0(preloading)-0.05mm max.
|
|
Standard
|
JIS B 1192
|
|
Certification
|
ISO9001, IATF16949
|
|
Delivery Package
|
Individual plastic bag and soft or solid protection for single ball screw and package in carton or wooden box.
|
