0606 larger screw lead ball screw
-
$30.00≥1 Others
- Min. Order:
- 1 Others
- Min. Order:
- 1 Others
- Transportation:
- Ocean, Land, Air, Express
- Port:
- ShangHai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | SuZhou |
|---|---|
| Productivity: | 2000pcs/month |
| Supply Ability: | 2000pcs/month |
| Payment Type: | L/C,T/T,D/P,D/A,Paypal |
| Incoterm: | FOB,Express Delivery,CFR,CIF,EXW,FAS,FCA |
| Certificate: | IATF16949 |
| Transportation: | Ocean,Land,Air,Express |
| Port: | ShangHai |
Factory directly supply mini custom ballnut diameter 6mm pitch 26mm ball screw 0606
Ball screws are ideal products for converting rotary motion into linear motion, or converting linear motion into rotary motion.
Ball screw is the most commonly used transmission element in tool machinery and precision machinery. Its main function is to convert rotary motion into linear motion, or convert torque into axial repetitive force, with high precision, reversibility and high Efficiency characteristics. Due to its small frictional resistance, ball screws are widely used in various industrial equipment and precision instruments.
The ball screw consists of a screw, a nut, a steel ball, a pre-press, a reverser, and a dust filter. Its function is to convert rotary motion into linear motion, which is a further extension and development of Acme screw. The important significance of this development is to change the bearing from sliding action to rolling action.
|
Material
|
Stainless steel or GCr15 ; others available upon request
|
|
Dimension
|
Norminal Diameter : from 4 to 40mm
|
|
Thread Direction
|
Right hand thread, left hand thread, bi-directional thread all available
|
|
Accuracy Grade
|
C3 C5 C7
|
|
Application
|
Automatic controlling machines, semi-conductor industry, general industrial machinery, machine tools, medical equipment, parking systems, measuring instrument, Automatic computer strip machine, Gantry cranes, Gantry robot, 3D engraving machine etc.
|
|
|
The marked price in the page is not the authentic transaction value. Because the category of screw’s products belongs to customized products, the actual price should be given corresponding discount by products’ specifications and order quantity.
|
1. We Screwtech is a professional manufacturer of Ball Screws, custom ball screw, miniature ball screw.Also the unique manufacturer for mini ball screws in China mainland.
2. We are factory:We can offer you products of high quality with competitive price and fast delivery.
3. Customized service:Various models are available upon request.
4.We can produce the same size as HIWIN, TBI, PMI, and THK.
Features of our mini ball screw
High mechanical efficiency
Zero Axial play and light preload
Accuracy grade of C3, C5, C7
Long service life
Smooth running
1.We have business rlations with clients both domestic and abroad.
2.With the high quality,good service as well as reasonable price,
We've kept steady and large exporting to Europe, Northern America, Australia,Korea and so on.
