Hollow shaft Ball Spline SC08T2NS-1000+S

Hollow shaft Ball Spline SC08T2NS-1000+S，the ball spline uses the balls installed in the outer cylinder of the spline shaft to smoothly roll and transmit torque in the precision ground rolling groove. It adopts a unique contact point design and has a larger contact angle (40°) In addition to high sensitivity, it can also greatly increase the load capacity. It is suitable for environments with excessive vibration and shock loads, high positioning accuracy requirements, and high-speed motion performance. It can also play an effective role in this type of environment.Hollow shaft Ball Spline SC08T2NS-1000+S, we make full use of features of Miniature Ball screw manufacture and super compact design actuator can achieved the high precision C3 according to our customers’ requirement. The diameter of one of the screw shaft ends must be less than the screw shaft root diameter, otherwise ball nut cannot be installed.
For Application field, Hollow shaft Ball Spline SC08T2NS-1000+S also used in machine tools, robots and precision assembly equipment. High precision ball screws are used in steppers for semiconductor manufacturing.Ball screws are used in aircraft and missiles to move control surfaces, especially for electric fly by wire, and in automobile power steering to translate rotary motion from an electric motor to axial motion of the steering rack.

Features：
(1) Lead Accuracy Up to Grade C3 C5 C7 and C10 ,screws have been Standardized. C5 on request.
(2) Hollow shaft Ball Spline SC08T2NS-1000+S are interchangeable between ground and rolled screws.
(3) Available to ship separately ball screw and ball nuts can be shipped separated ensure shortest delivery time. The ball nuts are standardized with light preload, also the preload value can be adjusted to zero or heavy.
The ball spline is equipped with 3 rows of load steel balls on the outer diameter of the spline shaft, and adopts the Gothic design so that the 3 rows of steel balls can bear both clockwise and counterclockwise torque at the same time to increase the service life and rigidity. Each row of steel balls continuously circulates the entire row through a special synthetic resin circulator installed in the spline cap. Therefore, even if the spline shaft is extracted from the spline cap, the steel balls will not fall off.

Main Features

1.High mechanical efficiency
2 .Axial play
3. High precision
4. Long service life

Material: GCR15 or Stainless Steel
Performance: high-precision
Type: Milled Thread
Nominal Diameter: 6mm
Lead: 1m
Accuracy grade: C3, C5, C7
Other characteristics:Smooth running
Name: Ball Spline
Brand: WKT
Original: Suzhou, China (Mainland)

Packaging Details:
In cartons or Wooden cases upon your requirement
For samples:
we have DHL, FEDEX VIP account, so the shipping freight will be much cheaper after discount.
For bulk order:
we have freight forwarder to ship by air,by train or by sea.You can also arrange shipping through your own agent.
Port:
Shanghai
Lead Time:
10~30 days
