Belt type loop winding machine for transformer coil

A two-way winding winding machine includes a winding machine body and a reverse winding device; the winding machine body includes a winding machine base and a winding machine shaft, and the winding machine shaft is installed on the winding machine On the base; the reverse winding device includes a support arm, a guide rail, a slider bracket, and a roller; the support arm is fixedly erected above the base of the winding machine, and the support arm is divided into a vertical arm and a horizontal arm. The vertical arm has two and is symmetrically fixedly connected to both sides of the winding machine base, both ends of the horizontal arm are respectively fixedly connected to the vertical arm, and a guide rail is also fixedly connected to the cross arm, and the guide rail is A slider bracket is slidably connected, and the slider bracket is also provided with a roller that can rotate around its own axis. The coil winding work in clockwise and counterclockwise directions can be completed on the same side of the winding machine.

Features:

1. Environmental protection, low noise and high efficiency;

2, the amount of storage line can be over sized

3, can choose different cable direction, winding angle and segmentation angle;

4, photoelectric sensor switch technology, high precision, accurate circle length;

5, stepper motor cable, the spacing can be precisely controlled;

Product parameters:

Applicable wire diameter: 0.18-0.5 mm

Maximum number of revolutions: 1600 rpm

Number of winding axes: 1

Spindle motor: DC 370 W

Cable motor: 9V Stepping Motor

Wire diameter: 0.01-9.99 mm

Net weight: about 40 kg

Minimum completed inner diameter: 4 mm

new Belt Type Loop Winding Machine

1. Q: Are you a manufacturer or a trading company?

A: We are a manufacturer's factory; we can customize the winding machine according to your requirements.
