Male 4pin Field-wireable M12 T-Code Power Connector
- Min. Order:
- 10 Bag/Bags
- Min. Order:
- 10 Bag/Bags
- Transportation:
- Ocean, Land, Air, Express
- Port:
- SHANGHAI, NINGBO, GUANGZHOU
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 2000PCS/Month |
| Payment Type: | T/T,D/P,L/C,D/A,Paypal |
| Incoterm: | FOB,CFR,CIF,EXW,FAS |
| Certificate: | CE |
| Transportation: | Ocean,Land,Air,Express |
| Port: | SHANGHAI,NINGBO,GUANGZHOU |
Male Straight 4pin Field-wireable M12 T-Code Power Connector.M12 series circular Connectors can provide more types of products, foolproof interface types have more than 10 options, not only can achieve signal transmission, M12 Connector T-code can also achieve up to 10Gbps data transmission, S and T-code can also achieve high-power transmission in a limited space, protection level can reach P67 and above.M12 circular Connector including, m12 s-code, m12 t-code, m12 l-code, m12 k-code power connector.We sell all kinds of M8 connector, m12 connector, m23 connector, and m40 connectors.If you want know more about our products,please visit our homepage.Factory direct sales, reliable quality, preferential prices, and guaranteed after-sales service.
| Name: |
M12 power connector |
| Pin out: | 4 pole |
| Gender: | Male |
| Supply voltage: | 60V AC/DC |
| Current per contact(40°) | max. 12A |
| Connection diameter: | max.1.5mm2 |
| Housing material: | CuZn, nickel plated |
| Wiring method: | Screw terminals |
| Protection: | IP67(EN60529) When plugged and screw down |
| Temperature range: | -25...+85℃ |
