Stainless Steel Argon Arc Welding Pressure Gauge

 The Ergonomic Pressure Gauge produced by our company are used in pneumatic and heating systems as well as in machinery and industrial applications due to their technical advantages such as high accuracy, easy detection and simple operation. We have a complete production line, the whole production line is operated by experienced technicians, the production of Wearing Feature Pressure Gauge materials are selected high-quality materials, product quality is reliable. Cost effective. Our Anti Static Pressure Gauge have competitive price, 100% inspection before delivery, and can be customized according to your needs in different appearance, we hope the thoughtful service can make you satisfied.

Capsule pressure gauge

Application

*EN837-3

*With zero correction

*Wetted parts made of stainless steel

Technical data

*Nominal size in mm

  63, 100,160

*Accuracy Class (according to EN837-1)

   1.6

*Measuring ranges

    0 … 25mbar to 0 … 1000mbar and all corresponding vacuum and compound ranges with overpressure protection

*Application area

   Steady:  full scale value

   Dynamic load: 0.9 X full scale value

    Short term: 1.3 X fully scale value

*Operating temperature range

     Ambient: -20 …. +60℃

     Medium: +60℃ maximum

*Temperature performance

    When the temperature of the measuring system deviates from the reference temperature (+20℃): max.±0.6%/10k of the span

*Degree of protection

    IP32 (EN 60529)

*Standard Version

   Process connection

    Stainless Steel, bottom or centre back

    NS 63      G1/4B  -- SW14

    NS 100,160  G1/2B – spanner size SW22

*Pressure element

    Capsule element, Stainless steel 316L

*Movement

    Copper alloy

*Dial

  Aluminium, white,

   Dial marking black

*Pointer

   Aluminium, black

     Zero correction

    From the front

*Case

   Stainless Steel 304

*Bayonet type bezel

  Stainless steel 304

*Window

   Laminated safety glass
