Gr5 titanium alloy tube
-
USD20≥100 Kilogram
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF, EXW
- Min. Order:
- 100 Kilogram
- Min. Order:
- 100 Kilogram
- Delivery Time:
- 30 Days
- Transportation:
- Ocean, Air
- Port:
- Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 80 ton/month |
| Supply Ability: | 80 ton/month |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW |
| HS Code: | 81089040 |
| Transportation: | Ocean,Air |
| Port: | Shanghai |
Ti-6Al-4V (GR 5) is an alloy consisting of 6% aluminum, 4% vanadium, and 90% pure titanium. Gr.5 has excellent corrosion resistance and higher mechanical properties than stainless steels and 3Al2.5V Titanium, 6Al4V Titanium is one of the most widely used titanium alloys, easy to find it as bars, sheets, forgings and discs etc. But seldom in tube and pipes.
Ti-6Al-4V (GR 5) has very strength and hardness, really hard or can't make the pipes by cold worked. Unidus Titanium can supply some Ti-6Al-4V pipes by hot worked and machining.
Chemical Composition
|
Al |
V |
N |
H |
O |
Fe |
C |
|
5.5 – 6.75 |
3.5 - 4.5 |
≤0.05 |
≤0.015 |
≤0.20 |
≤0.40 |
≤0.08 |
Mechanical Properties
|
|
Ultimate Strength |
Yield Strength |
Elongation 2" |
||
|
Ksi |
Mpa |
Ksi |
Mpa |
% |
|
|
Hot Worked |
130 |
895 |
120 |
828 |
10 |
Titanium Tube Grades Comparison Table
|
Grade |
UNS |
ASTM/ASME |
W.Nr |
AFNOR |
|
6Al4V Titanium |
R56400 |
Grade 5 |
- |
T-A6V |
Grade 5: Titanium Alloy Gr 5 Ti6Al4V (Ti64) is the most widely used titanium alloy, it has high mechanical properties, but low ductility. Gr 5 is also classed as an alpha-beta alloy and most widely used in high strength applications including aerospace, offshore, marine and power generation.
