Blowing Filling Capping Combi Block
Liquid Filling Machine
Liquid Filling Machine
Adopt 316 integral casting filling head, with high integrity and long service life;
Automatic Bottle Edible Oil Soap Filling Packing Machine
-
$2000.00≥1 Bag/Bags
- Min. Order:
- 1 Bag/Bags
- Min. Order:
- 1 Bag/Bags
- Transportation:
- Ocean
- Port:
- Shanghai Port
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Productivity: | 4000BPH 500ml |
| Supply Ability: | 20 sets per month |
| Payment Type: | L/C |
| Incoterm: | FOB |
| Certificate: | CE ISO |
| HS Code: | 8422302100 |
| Transportation: | Ocean |
| Port: | Shanghai Port |
Product Description
Product Description
It can be used for filling various viscous materials such as food, dailychemical, vegetable oil, jam, honey, syrup and so on.
Technical Parameter
|
Production Capacity
|
4000BPH (500ml)
|
|
Applicable Bottle
|
Length 80-220mm, Height 60-300mm
|
|
Accuracy
|
±0.2%
|
|
Air Pressure
|
0.6-0.8Mpa
|
|
Voltage
|
220V, 380v, customized
|
|
Power
|
1.5kw
|
|
Dimension
|
2400×1300×2300
|
|
Weight
|
1300kg
|
Liquid Filling Machine,Bottle Filling Machine Manufacturer
Filling And Capping Machine
Features
1.
PLC programming control, servo motor drives a stable double-screw transmission mechanism to ensure accurancy and stability when the piston cylinder is pushed. It can achieve fast and slow filling;
PLC programming control, servo motor drives a stable double-screw transmission mechanism to ensure accurancy and stability when the piston cylinder is pushed. It can achieve fast and slow filling;
The conveyor belts are equipped with coordinated photoelectric to intelligentlydetect the bottle-in and bottle-out. In case of bad conditions, they can automatically stop, reduce manual intervention and intelligent;
4.
Piston seals with PTFE carburizing technology, which improve wear resistance, longer service life, and reduce maintenance costs;
5.
Hoppers, valves, piston cylinders, filling heads all adopt live connection devices, which is convenient for replacement of sealing rings and disassembly for cleaning and disinfection;
6.
The components that need to be adjusted are all connected by quick connection. It is very convenient to replace the specification and adjust them;
7.
The whole electrical control system adopts well-known electrical brands (Schneider, Siemens), integrated electrical control system, more stable and reliable, safe, green, low energy consumption, environment protection (the electrical configuration can be changed according to customer requirement);
8.
The whole machine can be used for bottles of different specifications, easy to adjust, and can be complete in a short time.
Adopt imported photoelectric detection and induction, accurate positioning, filling with bottles, no filling without bottles, automatic counting function.
|
NO.
|
Item
|
Brand
|
|
1
|
Touch Screen
|
Weinview, Taiwan
|
|
2
|
PLC
|
Mitsubishi, Japan
|
|
3
|
Solenoid Valve
|
AirTAC, Taiwan
|
|
4
|
Frequency Converter
|
Schneider, France
|
|
5
|
Breaker
|
Schneider, France
|
|
6
|
Servo Motor
|
Panasonic, Japan
|
|
7
|
Switch
|
Schneider, France
|
