120°Beam Angle RGB DMX512 LED Linear Light CV5E

120°Beam Angle RGB DMX512 LED Linear Light CV5E

Linear Light, Led Linear Lighting, Contour Linear Lighting, Linear Light Fixture, RGBW LED Linear Lights, DMX Linear Light

 Features

■ Elegant slim profile outdoor  linear LED luminaire for large scale building façade contour outliners, video display and other decorative lightings applications.

■ Choice of Cree, Lumileds and Osram LEDs for high colour fidelity, consistency and long lifespan.

■ Available in whites, mono colour and RGB.

■ Corrosion-resist extruded aluminum body and high quality translucent curve-shape UV stabilized polycarbonate diffuser and end-caps for smooth and even light distribution. Wide view angle ≥120°.

■ Continuous line of light with no dark spots when luminaires are connected in cascade.

■ DC24V input power with built in stabilizer that allows voltage variance up to 10V. Constant current drive with PWM control ensures that all luminaires are consistent at the same brightness level and smooth colour changing. Stainless steel adjustable tilt mounting bracket and patented waterproof fast -clip connectors for fast installation. High wind resistance up to 45m/sec.

■ Customized lengths and colour available to match façade design features and architectural intent.

■ DMX control with auto-address function for quick setup and maintenance. Weather-sealed and IP65 rated.

 Parameters

■ LED source:CREE/OSRAM/LUMILEDS SMD
■ Power Rating: 14.4W, Input Voltage:DC24V
■ CCT:RGB, DMX 512
■ LEDs:60 LEDs
■ Beam Angle:≥120°
■ Dimension: 1000*27.1*43.1mm(without bracket)
■ Protection: IP 65
■ Operating temperature:-40 ~ +50℃
■ Material (Housing): Aluminum+PC(transparent / diffuser)
■ Cable length: 500mm with waterproof connectors
■ Cable (2 in/2 out)
■ Rotary bracket with 120D/Fixed bracket/  Clip spring bracket
■ Pixels:20
