Select plate making equipment and process
After determining which single layer CTP plate number technology to introduce, it is necessary to investigate the type of CTP plate making machine. When choosing platemaking machine to consider several aspects:
(1) the choice of plate making machine light source each CTP technology plate making machine has two or more than two kinds of light source. There are two kinds of thermal sensitivity: 830nm and 1064nm. Silver and optical polymerization technology can be used for 410nm, 488nm and 532nm, respectively. Therefore, it is necessary to choose the current mainstream products. The two companies purchased obsolete plate-making machines (488nm silver plate-making machines and 1064nm hot plate-making machines) and left the equipment idle.
(2) The choice of equipment must take into account the layout factor. When selecting equipment, consider the number of manufacturers of materials compatible with the equipment. The more kinds of materials suitable for equipment, the better. Not only is the technology long, but the price is low. Silver salt technology should be the first one to introduce Single Layer Ctp Plate Options in China, which has enjoyed unlimited success. However, because the number of plate manufacturers is small, the pace of localization is slow, the current situation is on the low side.
(3) The selection of Single Layer Ctp Plate Online must take advanced technology into account, and the supporting technology is very important. Only in this way can advantages be fully reflected. A user in China spends a long time (1 to 2 hours) on RIP files due to a mismatch in the purchase process. As a result, the release speed is severely affected and the device is abandoned.
TECHNICAL DATA
|
UV-PH HIGH SENSITIVITY POSITIVE CTcP PLATE |
|
|
Plate Type |
UV-PH type UV-CTP plate, also used as high sensitivity PS plate. |
|
Application |
Commercial sheetfed and rotary press printing |
|
Substrate |
Electrochemically grained and anodized aluminum |
|
Gauge |
0.15/0.20/0.25/0.30/0.40mm |
|
Maximum width |
1320mm |
|
Spectrum scope |
350-460nm UV light, especially 400-410nm UV laser |
|
Sensitivity |
40±5 mw(Cron UV-4632CI platesetter Parameter 1000 rpm) |
|
Safe light |
UV filtered or Yellow light |
|
Coating color |
Blue-Green |
|
Dot reproduction |
2-98% @ 250 lpi |
|
Applicable platesetter |
main UV-CTP platesetters such as Cron,luscher,Amsky,basysPrint. |
|
Run length |
Above 100,000,which may vary against the different press, ink and stock condition |
|
Developer |
Common positive offset plate developer |
|
Development |
Conductivity: min 55ms, max 65ms Temperature: 20-25°C PH 13.00-13.40 |
|
Packaging |
0.15mm 100 pieces/box 0.25/0.30mm 50 pieces/box if length <1030mm; 30 pieces/box if length ≥1030mm; 25 pieces/box if the area > 1m2 |
|
Shelf life |
18 months when stored in a light-free area away from excessive cold, heat and high humidity |
|
Transport and storage |
Store plates at in their packaging, away from excessive cold, heat or high humidity. Recommended condition is: temperature 10-26°C & RH between 40 - 70%. |
