Rubber Air Hose

Established in 1990, SUZHOU SEAPEAK CO., LTD. is one of the professional PVC hose pipe manufacturers and hose fittings manufacturers in China. Covering 6000 square meter, We now have annual sales turnovers in excess of USD15,000,000 and more than 60 workers at our factory. Our ISO9001 certification further demonstrates our commitment to providing high quality products.

Black Rubber Air Hose
Construction:
Tube: NR & SBR synthetic rubber, black color.
Reinforcement:1ply or 2ply high tensile polyester thread braiding
Cover: NR & SBR synthetic rubber, smooth or wrapped surface, black, yellow, red available

Application:
Flexible rubber tube is mainly used for conveying of air, inert gas and water in mining, construction, engineering, shipbuilding, steel production etc.
Temperature: -40℃(-104℉)to 70℃(+158℉)

Specification of Rubber Air Hose
I.D. I.D. O.D. W.P. B.P. Radius Length Weight
INCH MM MM BAR BAR MM M KG/M
3/16 4.8 11.5 20 60 30 100 0.16
1/4 6 13 20 60 35 100 0.19
5/16 8 15 20 60 50 100 0.23
3/8 9.5 17 20 60 60 100 0.28
1/2 12.7 21 20 60 70 100 0.41
5/8 16 24.5 20 60 90 100 0.51
3/4 19 29 20 60 125 100 0.77
1 25 36.5 20 60 150 50 0.89
1-1/4 32 43 20 60 230 50 1.08
1-1/2 38 50 20 60 270 50 1.37
2 51 64 20 60 400 50 1.78
