Trunnion Mounted Metal to Metal Seat Ball Valve

The API 6D trunnion mounted metal to metal seat ball valve has two floating seats with springs loaded, in which the ball is fixed at two pivot points, and the process pressure pushes the upstream seat against the ball's sealing surface. This trunnion mounted ball metal seat design applies continuous pressure against a trunnion mounted ball after the ball is installed. The metal to metal seat trunnion mounted ball valve is one kind of important oil and gas industry valves widely used in oil and gas industry when the working temperature is higher out of limitation of soft seat material or when it’s requested by abrasive service like black water. When the size bigger than 10” or pressure class higher than Class600, the trunnion type ball valve will be applied to replace floating ball valve. Trunnion valve can be applied to higher pressure class and bigger size.

Standard:

Basic Design: API 6D, ASME B16.47, BS5351

Face to Face: ASME B16.10, API6D, DIN3202, EN558

Flange Ends: ASME B16.5, ASME B16.47, EN1092

BW Ends: ASME B16.25

Pressure Test: API 6D, API 598, EN12266

Fire Safety: API 607, API 6Fa

Design Feature:

Hard Facing Seat, Metal to Metal Seat

3pcs Forged Steel Body, Side Entry

3pcs Cast Steel Body, Side Entry

2pcs Cast Steel Body, Side Entry

Trunnion Mounted Ball

Blow-out Proof Stem

Anti-Static Device

Fire Safety Design

Emergency Sealant Injector

DBB, DPE, SPE, High Temperature or Abrasive Service

Size Range: 2" to 24" (DN50 to DN600)

Pressure Class: Class 150 to Class 600

Material:

Body: WCB, CF8, CF8M, A105N, F11, F22, F304, F316, F51

Metal to Metal Seal: Base material + hard facing of TCC, STL Overlay, Nitriding

Operation:

Lever, Gear, Pneumatic Actuator

Optional:

Trunnion valve with Jacket, Trunnion Ball Valve with Stem Extension, Trunnion Mounted Valve with Carboline Painting

Thanks for your selection of RSF’s API 6D metal to metal trunnion mounted ball valve! If you have any inquiries of our oil and gas industry valves such as trunnion mounted ball valve, metal to metal seat trunnion ball valve, please don’t hesitate to call us or email us!
