EDM Die Sinking Machine G50

Mirror Grade CNC EDM Sinker Machine G50

EDM G50 machine application for

Copper / steel;   graphite 1 / steel;   graphite 2 / steel;   copper / aluminum alloy;   graphite 1 / aluminum alloy;   graphite 2 / aluminum, silver tungsten;   copper tungsten / steel, silver tungsten;   copper and tungsten / carbide;   copper / zinc alloy;    graphite / zinc alloy;   copper / copper alloys;

"T" sharp machine bed, "+" cross worktable structure, high rigidity casting, Hiwin liner guideway, famous parts

This is the base condition for G series CNC die sinking EDM machine.

G50 EDM sinker machine can reach very high working speeding but keeg good enough roughness and low electrode ware

Powerful system function make you very easy to operate a set high precision CNC EDM sinking machine

G series CNC die sinking EDM machine can reach very high speeding but keep good roughness.

The machine adopt famous parts like Panasonic servo motor, HIWIN linear guideway, HIWIN ball screw, Schneider electrical to make sure quality.

The system with a lot advanced technology for example automatic process function, automatic positioning function, automatic clean arc and short circuit. It includes tool raise high-speed adaptive system, discharge pulse detection system and energy pulse control system to short machining time and get best precision

• High Performance

• Roughness of Ra≤0.08um

• Electrode Consumption 0.01%

• CNC Mirror Sinker EDM

• Economic

• Precision ± 0.005mm

• Efficiency≥500mm3 / min

Mirror Grade CNC EDM Sinker Machine G50 Specification

Main Parts List
