Features
1.High Pressure Air Compressor
As a heart of water-cooling machine,Kinggle choose the original Industrial Air Compressor from European and USA with safety production inside,low noise,energy saving and long life.
2.Evaporator as water tank style
Thick stainless steel Evaporator with automatic water supplying device,the swell water tank during the installation will be saved,easy to install and maintain,and also suitable for the case of big temperature deviations,small flow.
3.Water-cooling condenser
Made from UKB latest outside threaded copper tube,good heat dissipation and small occupation.Use the latest CAD,CAM R&D technic,made form CNC which has a feature of compact structure,energy saving ,good shape and reliable performance.
4.Machine configuration
Equiped with exact electric temperature controller which control the water temperature between 5-20℃.inside which there is a overload protector,high pressure abnormal protector,imported dry filter and swell valve for stable running and easy repairing and maintaince.
5.Pump configuration for option
Imported high efficiency pump is available according to customer's requirement.
6.Multi function operation panel
There are current monitor,Electric Air Compressor on-off switch,pump on-off switch,electric temperature controller,safety running alert light on the panel.

Notes:

1.Rated cooling capacity is based on: chilled water inlet and outlet water temperature 12℃ /7℃,the cooling air inlet and outlet temperature 30℃ /35℃

2.Scope of work: chilled water temperature range: 5℃ to 35℃; chilled water inlet and outlet temperature difference: 3℃to 8℃.

The ambient temperature of condensation: Not higher than 35℃ (non-standard chiller ambient temperature of condensation can reach maximum 55℃,need to order production).

These models above can be customized according to customers' requirements.

Specifications and dimensions above are subject to change without notice.

Model Description: A represents air-cooled; D represents two compressors; T represents three compressors; F represents four compressors.

Notes:

1.Rated cooling capacity is based on :chilled water inlet and outlet water temperature 12℃/17℃.the cooling air inlet and outlet

temperature 30℃/35℃

2 Scope of work: chilled water temperature range: 5℃ to 35℃; chilled water inlet and outlet temperature difference: 3℃ to 8℃.

The ambient temperature of condensation: Not higher than 35℃ (non-standard chiller ambient temperature of condensation can reach

maximum 55℃ ,need to order production ).

These models above can be customized according to customers' requirements.

Specifications anddimensions above are subject to change without notice.

Model Description: A rapresents air-cooled; D represents two compressors; T represents three compressors; F represents four compressors.
