Plastic Juice Bottles For Beverage Packaging

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc. Mineral water bottle, Beverage bottle, juice bottle, water tank, cosmetic bottle, medicine bottle, jar can, nuts can, etc.

Technical Data for Blow Molding KHX-KS55UF2x6-500ml

1. General Issues
Machine operating manual including Hydraulic, Pneumatic, Assembly drawing, Water Cooled Water Chiller.
Max. volume of product single cavity 500mL
Total weight 8 ton 3.5-4.5bars Max. output 600pcsh (250mL product net weight 30-50g,Sufficient cooling water temperature at
8℃ with an intake pressure of between 3.5 to 4.5 bars, with a Min. difference between intake and outlet of 3 bars. )

2. Clamping Unit
Principle bi-direction synchronous clamping device with double axis.
Linear roller guidance horizontal.
Clamping force 150KN
Mold platens H x W 400 x 500 mm
Distance between the p;atens 150-550mm
Clamping unit stroke 300mm

3. Die Head
Type of die head Double lays head of accumulator.
Max mouth diameter 8- 20MM
Max. Storage volume
Type of temperature sensors K
Heater power 12KW
100 point WPS systerm controller (B&R) or   MOOG 100 poing

4. Extruder System
Extruder Screw Barre should be adequate to work with HDPE
Screw diameter 55-6530D
Nitride treatment barrel and screw.
Plasticizing efficiency 80-100 kgh (HDPE)
Feeding zone grooved with cooling water
Cast-aluminium heater, adopt European mode of connection
Type of temperature sensors
DC motor drive 13KW
Cooling by 5 cooling fans.
Raw material hopper with a window.

5.Blow System
Blow Moulding Machine Accessories mounted on linear guide under the mold.
Height adjustment mechainsm 150 mm
Blow pin updown stroke 150 mm , controlled by hydraulic cylinder
Parison closed
Mechanical adjustment for left and right

6. Take out system
Take out stroke 400 mm
Adopt lear guide and synchronous belt transmission of motor to advance and retreat
Gripper with the function auto cooling water

7. Hydraulic System
Hydraulic working pressure 100 -150 bar
Hydraulic system servo pump  60 Lmin
Hydraulic valvesYuken brand
Oil Temperature sensor showing the screen
Motor power 5.5-11 KW
Servo system
Servo valve (REXROTH--From Germany)
Servo oil source4KW
Piston pumpYUken (YUKEN--From Japan)
Threads of hydraulic block use of screw joint GE(ISO 1179)

8. Pneumatic System
Pneumatic cylinders AIRTEC
Pneumatic valves AIRTEC
Max. pressure of all components 10 bar
Max. pressure of gauge 6-8bar

9.Control System
Control System Moog
Servo WDS control system
 Moog 100point.
Full color 12.4"
Full color 12.4" screen.
Recipe and machine data storage on memory stick (CF)
Emergency stop push buttons (rotationally release) without key
All electric components needs to be for power supply 220V380V, 50Hz, controller DC24V,
Total rated power 76 KW
Average energy consumption 22-30 KW
Main components (Air switch, Contactor) :Schneider intermediate relay Schneider
Invertot of extuder motor PARK
Linear transducer Gefran
Proximity switch Schneider

Water Cooling Chiller
All pipes for cooling water made of rubber material.
Separate cooling water circuit for Mold, Blow pin, Extruder feeding zone, Oil cooling.
Water consumptions 10m3h

11.Machine frame
Clamping unit should be forward 600 mm, for mold changing
Aluminum profiles for safety doors, with plastic window.
Machine color according requirement of customer
Overall dimensions of machine LxWxH 2.8 x 2.2x 2.6 m
