Hand washing liquid bottle blow molding machine

Plasticizing ability: the extrusion machine is driven by frequency conversion motor, which can realize the requirement of screw speed change in blow molding process. The screw with big slenderness ratio can produce many kinds of materials, strong plasticizing ability, high yield and low energy consumption. The material can be heated by a resistance heating ring, the temperature of the barrel is controlled by a computer, and the temperature is stable and uniform when the heating is rapid. Assemble different mould heads on two or three extruder coextrusion systems, blow the liquid level line or double layer and three layer products.

KHX-KS65UF2x4-500ml

Technical Data for Blow Molding Machine Head   KHX-KS65UF2x4-1000ml
1. General Issues
Machine operating manual including Hydraulic, Pneumatic, Assembly drawing, Cooling water.
Max. volume of product: single cavity 500mL
Total weight 12 ton 3.5-4.5bars
Max. output 600pcs/h (250mL product net weight 30-50g,Sufficient cooling water temperature at
8℃ with an intake pressure of between 3.5 to 4.5 bars, with a Min. difference between intake and outlet of 3 bars. )

2. Clamping Unit
Principle: bi-direction synchronous clamping device with double axis.
Linear roller guidance horizontal.
Clamping force: 150KN
Mold platens H x W 400 x 500 mm
Distance between the p;atens: 150-550mm
Clamping unit stroke: 300mm

3. Die Head
Type of die head: Double lays head of accumulator.
Max mouth diameter: 8- 30MM
Max. Storage volume:
Type of temperature sensors: K
Heater power: 15KW
100 point WPS systerm controller (B&R) or   MOOG 100 poing

4. Extruder System
Screw Extruder Barrel should be adequate to work with HDPE
Screw diameter: 65-75/30D
Nitride treatment barrel and screw.
Plasticizing efficiency: 80-100 kg/h (HDPE)
Feeding zone grooved with cooling water
Cast-aluminium heater, adopt European mode of connection
Type of temperature sensors:
DC motor drive: 15KW
Cooling by 5 cooling fans.
Raw material hopper with a window.

5.Blow System
Blow Mold Machine Accessories system mounted on linear guide under the mold.
Height adjustment mechainsm 150 mm
Blow pin up/down stroke: 150 mm , controlled by hydraulic cylinder
Parison closed
Mechanical adjustment for left and right

6. Take out system
Take out stroke 400 mm
Adopt lear guide and synchronous belt transmission of motor to advance and retreat
Gripper with the function: auto cooling water

7. Hydraulic System
Hydraulic working pressure 100 -150 bar
Hydraulic system servo pump : 80 L/min
Hydraulic valves:Yuken brand
Oil Temperature sensor showing the screen
Motor power: 7.5-15 KW
Servo system
Servo valve: (REXROTH--From Germany)
Servo oil source:4KW
Piston pump:YUken (YUKEN--From Japan)
Threads of hydraulic block use of screw joint GE(ISO 1179)

8. Pneumatic System
Pneumatic cylinders AIRTEC
Pneumatic valves AIRTEC
Max. pressure of all components: 10 bar
Max. pressure of gauge: 6-8bar

9.Control System
Control System:Moog
Servo WDS control system:
Moog 100point.
Full color 12.4"
Full color 12.4" screen.
Recipe and machine data storage on memory stick (CF)

Emergency stop push buttons (rotationally release) without key
All electric components needs to be for power supply 220V/380V, 50Hz, controller DC24V,
Total rated power: 76 KW
Average energy consumption: 22-30 KW
Main components (Air switch, Contactor) :Schneider intermediate relay: Schneider
Invertot of extuder motor: PARK
Linear transducer: Gefran
Proximity switch: Schneider

Water Cooling Chiller
All pipes for cooling water made of rubber material.
Separate cooling water circuit for Mold, Blow pin, Extruder feeding zone, Oil cooling.
Water consumptions: 10m3/h

11.Machine frame
Clamping unit should be forward: 600 mm, for mold changing
Aluminum profiles for safety doors, with plastic window.
Machine color: according requirement of customer
Overall dimensions of machine LxWxH: 2.8 x 3.2x 3.0 m
