Single- girder overhead cranes 10t

Single- girder overhead cranes 10t

Description

This crane belongs to light duty crane, can be used with Wire Rope and Chain Electrical or Manual Hoist. The lifting capacity is 10t.

Lifting capacity of single girder overhead crane is from 1t to 20t, Span from 5 m to 34 m, working condition is A3-A5, Working temperature is -25°C to +40°C.

Components

a) Steel structure: main bridge beam, end carriages with wheels driven by motors.

b) Hoisting mechanism: electric hoist mounted on main bridge beam.

c) Electrics: electric box/cables/operator.

Control method

a) Wireless Remote Control; b) Pendent Line with Press Button; c) Cabin Control

Painting

Epoxy zinc rich primer + micaceous iron oxide anchor coat + aliphatic polyurethane top coat

Color: according to your demand.

Average thickness: about 100 microns

Power supply

380V/50HZ or as per client's requirement

Why Choose Us

1. Excellent service guarantees you the best purchasing experience.

2. Large production capacity and professional workers guarantees you the short delivery.

3. Strict delivery inspection guarantees you the high quality products.

After-sale Service

1. One year warranty for whole equipment

2. Low charge for continue maintenance when warranty is expired

3. Exclusive engineer support at any time

4. We can provide free training to end-users
