female header

pitch:1.00mm female header

double row smt type

spec:

current rating:1.0Amps

insulator resistance:500Megohms Min

dielectric withstanding:AC 300V

contact resistance:20mΩ Max

operating temperature:-40℃-+105℃

materials:

contact material:phosphor bronze

insulator material:polyester ul 94v-0 nylon-6t

finish:gold,tin or dulex plated

CNT was located in kunshan city where is near shanghai port and very convenient for shipping. We have founded the company in 2007 and build ERP from 2012. There are less than 50 persons in our company so we save a lot of labor cost than the big scale company.

There are 4 lines for assembling connector and 2 different inspection line. Our products occupied for 60% connector market in china mainland. Better quality and service is our strong point.

Our main product includes 0.3/0.5/0.8/1.0/1.2/1.27/2.0/2.54/3.96mm pitch pin header and female header , also with USB 2.0 USB 3.0, USB A type male/female type, USB B male/female. D-SUB , FPC/FFC, Cables and wires, etc.

Our main clients such as Mi, Midea,Gree,Hisense,etc.The connector application is computer, cellphone , loudspeaker, TV, DVD, digital camera, internet, car and air field.

Good reputation ,old workers, quick shipping, lower price ,small order and OEM ODM is available .We assure giving you a completing price .Welcome new and old clients come to order.
