run stable home villa lift elevator with high quality made in China
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 14 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 60 Thousands Sets /year |
| Supply Ability: | 6000 sets per year |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | TUV CE ISO |
| Transportation: | Ocean,Land,Air |
Joylive passenger elevator uses the most advanced lift control system technology variable frequency(VVVF) drive, which combined fully computer control technology with the data net system and modularized structure.
Joycity Commercial Passenger elevator:
For Large Scale Building Vertical passenger flow
Provide planning design production and instCllation and monitoring service of operation.
For Luxury Residential Buildings/Shopping centers/CBD/Hotels/Transportation Junctions and other Public Building
Small machine room home elevator parameters
| Load capacity (Kg) | Rated Speed m/s | Car Dimension CW*CD(mm) | Door Opening Dimension EW*EH(mm) | Door Numbers | Door Opening Type | Standard Shaft Dimension HW*HD(mm) | Max Shaft Dimension HW*HD(mm) | Standard Pit Depth Pd(mm) | Standart top floor height Th(mm) |
| 630 | 1 | 1400×1100 | 800×2100 | Single Opening Door | Center Opening Door | 1900×1700 | 2700×2100 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 630 | 1 | 1100×1400 | 800×2100 | Single Opening Door | Center Opening Door | 2800×1900 | 2800×1900 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 800 | 1 | 1400×1350 | 800×2100 | Single Opening Door | Center Opening Door | 1900×1950 | 2700×2350 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 800 | 1 | 1400×1350 | 800×2100 | Single Opening Door | Center Opening Door | 1900×1950 | 2700×2350 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 1000 | 1 | 1600×1400 | 900×2100 | Single Opening Door | Center Opening Door | 2100×2000 | 2900×2400 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 1000 | 1 | 1400×1600 | 900×2100 | Single Opening Door | Center Opening Door | 2300×2100 | 3100×2100 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 1250 | 1 | 1900×1500 | 1100×2100 | Single Opening Door | Center Opening Door | 2400×2200 | 3200×2600 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 1350 | 1 | 1900×2000 | 1100×2100 | Single Opening Door | Center Opening Door | 2400×2300 | 3200×2700 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 | |||||||
| 1600 | 1 | 2000×1700 | 1100×2100 | Single Opening Door | Center Opening Door | 2500×2400 | 3300×2800 | 1400 | 4450 |
| 1.5 | 1450 | 4500 | |||||||
| 1.75 | 1450 | 4600 |
1.Installation drawing and english manual will be provide with the product
2.All the structures will be tested before shipment
3.We provide 14months guarantee for the elevator
4.You can find us 24 hours through email, telephone or video online
About Joylive
Joylive Elevator Co., Ltd.* was founded in Kunshan city, Jiangsu province in 2002. After more than a decade`s development, Joylive has become a famous brand with the enterprise conception of "Intelligence, Environmental-Friendliness and Supreme Service" in the industry.
Joylive Factory Show
Flexible production line of cabin wall panel
Production line combine Salvagnini precise steel panel processing with the functions of automatic glue, welding and packing robot, and the whole line is remarkable smooth from products on-line of raw materials to welding, painting, packing.
Fully automatic production ling of landing doors
The whole production line is put into production order with the company ERP system, it can automatically completed feeding material, punching, cutting, folding, glue, welding and automatic packing and other processes.
Automatic laser cutting machine
It can not only cut carbon steel, stainless steel, aluminum and other conventional materials, but also can cut non-metallic materials stably and effectively, in addition to enhance the speed of sheet metal processing effectively, it can also process standard laser machining, coupling welding units, which greatly improves product accuracy and productivity
1.Is your product customized?
Yes,we can provide customized elevator depending on your detail requirement
2.Shipping&Prie term
FOB/CFR/CIF price term are all avaliable, we have professional forwarder help you arrange the shipment.
3.Spare parts
Every elevator has a package of spare parts sent along with the container.
Any spare parts get demaged because of quality within 12 months after the shipment date, we will express you it within 12 hours
4.Payment terms
30% will be paid as the deposit by T/T, the balance 70% be paid before shipment
