Four Weighing System Filling Machine

The company attaches great importance to scientific management and talent development, has abundant technical force, advanced technology, strict quality management system and working attitude of keeping improvement, all these ensure the enterprise to be in line with international standards, and promote the company to develop sustainably.

Polyester fiber filling machine having technology with Easy to operate PLC programmed time based automatic filling weight adjustment unit for last production.

Aim at filling fiber, Double filling ports for fiber filling machine, allow 2 operators working at the same time.

Fully automatic fiber filling machine, weighing and filling.

Max weight of ball fiber filling machine can reach to 80g, min is 1g.

Highest precision of polyester fiber filling machine reach to 0.1g.

Storage unit and weighing unit of fiber stuffing machine are combined together to reduce covering space.

Details:

Brand: Bealead

Model: 402D

Composed by: 1 feeding unit and 2 weighing units / filling station

Filling Pipes: 2

Scales by filling pipe: 2

Fillings by hour: 1000 lattices

Application: Apparel, Commodity, Textiles

Material Application: 50%- 90% down

Weight: 700kg

Filling Storage: 10kg

Weighing Range: 1g- 80g

Accuracy: 0.1g

Feeding Unit Size: 2.07* 1* 2.01m

Overall Size: 2.07* 2.4* 2.01m

Min. Site Area: 4m* 6m
