Automatic Padded Garments Filling Machine

Get Latest Price

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Transportation:: Ocean, Air

Port:: Shanghai

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Supply Ability:	200 SETS/MONTH
Payment Type:	L/C,T/T
Incoterm:	FOB,CIF,EXW
Certificate:	ISO 9001
Transportation:	Ocean,Air
Port:	Shanghai

Product Description

402E automatic fiber filling machine is a professional machine to fill all kinds of fiber. Fiber stuffing machine is our R&D new creation of double filling stations.

Each station of ball fiber filling machine with 1 filling pipe, double weighing system.

Fiber filling machine's weighing range is 5-130g, capable of filling both large and small lattice panels.

Details:

Brand: Bealead

Model: 402E

Composed by: 1 feeding unit and 2 weighing units / filling station

Filling Pipes: 2

Scales by filling pipe: 2

Fillings by hour: 600 lattices

Application: Apparel, Commodity, Textiles

Material Application: 50%- 90% down

Weight: 700kg

Filling Storage: 12kg

Weighing Range: 5g- 130g

Accuracy: 0.1g

Feeding Unit Size: 1.7* 1.4* 1.9m

Weighing Unit Size: 1.5* 0.6* 1m

Overall Size: 1.7* 4.9* 1.9m

Min. Site Area: 4m* 6m

Main Specification

Voltage	380V	Air Tank	≥1m³
Air Pressure	0.6- 0.8MPa	Air Compressor Power	11KW
Min. Air Pressure	0.5MPa	Air Compressor Exhaust	≥1.6m³/min
Max. Power	3.5KW	Air Monitoring System	-
PPR Pipe	1.5 inch	Down Returning System	-
Pipe Distance	≤20m	Humidity Control System	√

Accessories

Company Information

ChangShu Bealead Automatic Machine Co.,LTD, located in changshu, jiangsu ,china. Close to ShangHai Port, driving for 1.5hours, transportation convenient.

Our company is R&D manufacturer of intelligent device for clothing production. We are in leading

position in Down feather filling area, covered most of Chinese market, Bosideng, Luo Lai, UNI QLO, are our customers.

We also have agents overseas, and more than 20 technecians for after sales service. They could answer you and service you at the first time you need.

Our Factory

Down Filling Machine Factory
