Powerfully Fiber Stuffing Machine
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CIF
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Air
- Port:
- Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Supply Ability: | 200 SETS/MONTH |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF |
| Certificate: | CE/ISO 9001 |
| Transportation: | Ocean,Air |
| Port: | Shanghai |
246B automatic fiber filling machine applied for Polyester balls filling material and down material, high valuable fiber filling machine.
Down filling machine has 2 filling ports, means 2 workers can operate at the same time, it's efficiency.
As well this automatic down filling machine has 4 scales for each filling port, speed improved.
Details:
Brand: Bealead
Model: 246B
Composed by: 1 feeding unit and 2 Weighing Units/ Filling Station
Filling Pipes: 2
Scales by filling pipe: 4
Fillings by hour: 1800 ( Polyester Balls)/ 1400 ( Down)
Application: Apparel, Commodity, Textiles
Material Application: 50%- 90% down
Weight: 1000kg
Filling Storage: 10kg
Weighing Range: 0.2g- 20g
Accuracy: 0.01g
Feeding Unit Size: 2.4* 0.9* 2m
Weighing Unit Size: 1.6* 0.5* 0.9m
Overall Size: 2.4* 4.2* 2m
Min. Site Area: 4m* 5m
Main Specification
|
Voltage |
380V |
Air Tank |
≥1m³ |
| Air Pressure |
0.6- 0.8MPa |
Air Compressor Power |
11KW |
| Min. Air Pressure |
0.5MPa |
Air Compressor Exhaust |
≥1.6m³/min |
| Max. Power |
3.5KW |
Air Monitoring System |
√ |
| PPR Pipe |
1.5 inch |
Down Returning System |
√ |
| Pipe Distance |
≤20m |
Humidity Control System | - |
