Single Head Down Stuffing Machine
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean
- Port:
- Shanghai
Your message must be between 20 to 2000 characters
Contact NowPlace of Origin: | CHINA |
---|---|
Supply Ability: | 200 SETS/MONTH |
Payment Type: | L/C,T/T |
Incoterm: | FOB,CFR,CIF |
Certificate: | CE/ISO 9001 |
Transportation: | Ocean |
Port: | Shanghai |
I believe you want a small down filling machine which Can fill both jackets and sleeping bags, so great!
As well automatic down filling machine Can be sample filling machine, suitable for small factories. operated by one worker.
New model X, equipped with aviation joint for high output down filling machine, it is easy to install, and allows for plug and play.
Meanwhile 6 scales support each filling port of automatic fiber filling machine, accuracy reach to 0.01g.
Each weighing system of down garment filling machine works independently, that is if there`s problem in a single system, the down jacket filling machine can still operate normally.
Details:
Brand: Bealead
Model: DF-1603X
Composed by: 1 feeding unit and 1 weighing units/ filling station
Filling Pipes: 1
Scales by filling pipe: 6
Fillings by hour: 1000-1500 lattices
Application: Apparel, Commodity, Textiles
Material Application: 50%- 90% down
Weight: 920kg
Filling Storage: 10kg
Weighing Range: 0.2g- 20g
Accuracy: 0.01g
Feeding Unit Size: 2.1* 0.8* 2.1m
Weighing Unit Size: 1.8* 0.6* 0.95m
Min. Site Area: 5m* 6m
Main Specification
Voltage |
220V |
Air Tank |
≥1m³ |
Air Pressure |
0.6- 0.8MPa |
Air Compressor Power |
7.5KW |
Min. Air Pressure |
0.5MPa |
Air Compressor Exhaust |
≥1m³/min |
Max. Power |
2.5KW |
Air Monitoring System |
√ |
PPR Pipe |
1 inch |
Down Returning System |
√ |
Pipe Distance |
≤20m |
Humidity Control System | √ |
Accessories
Company Information
ChangShu Bealead Automatic Machine Co.,LTD, located in changshu, jiangsu ,china. Close to ShangHai Port, driving for 1.5hours, transportation convenient.
Our company is R&D manufacturer of intelligent device for clothing production. We are in leading
position in Down feather filling area, covered most of Chinese market, Bosideng, Luo Lai, UNI QLO, are our customers.
We also have agents overseas, and more than 20 technecians for after sales service. They could answer you and service you at the first time you need.
Our Factory
Exhibitions
CE Certificate
