automatic water filling machine

Jiangsu ASG Packaging Machinery Group co, Ltd is located in Jinfeng science and technology park, Zhangjiagang City, covering an area of 120 acres, with an international standard workshop of 30,000 square meters. It integrated research, development and manufacturing is a professional beverage and dairy packaging machinery manufacturer. Imported several sets of CNC machining center from the United States and Japan, with fixed assets of RMB 100 million.

technology area--beverage and the dairy packaging machinery, in recent years ASG has completed dozens of institute research projects, which including national torch plans industrialization project "liquid food aseptic automatically high-speed filling machine", "juice with pulp filling machine" and "liquid milk and beverage continuous high-speed packaging robot", participate in many national standards of developed, thereby enhance the leading position of industry. More attractive to Nestle, Coca Cola, Pepsi Cola, bright dairy, robust, Arowana, dongpeng group, Yangjiajia, Tianjin, Tianjin Nanji, Shanghai Yanzhong, Tianjin Huaqisuch famous enterprises, and with domestic and international market.

Company spirit of "quality win market, and brand make up splendid" business philosophy, with full enthusiasm, sincere cooperation attitude warmly welcome customers at home and abroad to visit our company.

Automatic water filling machine

XGF automatic 3 in 1 water filling machine is designed and manufactured based on the latest technology from Germany and Italy, for the demand of technical requirement of beverage production, as pure water and mineral water.

The filling mono-bloc works as follows: Bottles are fed from air conveyor into the filling machine mono-bloc via star wheel. Bottle clamp installed on the rotary wheel of the rinse will grip bottle mouth and make a 180° turn along a guide track to face the bottle mouth downward. In designated section of the rinse, rinsing water will jet out from special nozzles to flush bottle inside wall. After rinsing and dripping, bottles gripped by bottle clamp will make another 180° turn along a guide track to resume bottle mouth facing up position. Clean bottles are discharged out of the rinse by a star wheel to feed the filler. After entering the filler, bottles are retained by neck supporting carrier plates, which are actuated by bottle carrier mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process. Bottle carrier mechanism is lowered by a cam to disengage filled bottles with filling valves. Then bottles are transferred into the capper by a neck handling star wheel. Anti-rotation blades on capping heads will seize the bottleneck to prevent it from rotation and hold it in a upright position. The twist-on capping head will make revolving and rotating movement along with the machine to finish the complete capping process of cap picking, placing, twisting, and disengaging under the control of a cam. A discharge star wheel discharges finished bottles onto discharge conveyor belt to be conveyed out of the filling mono-bloc.

Model      Brand name

Filling valve    S.S 304

Rinsing and working platform       S.S 304

Breaker          SCHNEIDER

Contactor       SCHNEIDER

Motor start-up       SCHNEIDER

Midget relay SCHNEIDER

Indicator light        SCHNEIDER

Emergency stopper       SCHNEIDER

Frequency exchanger    MITSUBISH

PLC  OMRON

Touch screen          DIGITAL PROFACE

Proximity switch    TURCK

Photoelectric switch     BANNER
