Super Driller/EDM Drilling Machine
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Small Hole Drilling EDM Machine Specification
| Model | HQ703A | HQ703B |
| Work table Dimension | 550*360 | 550*360 |
| External Dimensions | 1000*750*2000 | 900*900*1800 |
| X*Y*Z travel | 350*250*(380+300) | 400*300*(380+250) |
| Max Loading | 350kg | 150kg |
| Drill Diameter | Ф0.15~Ф3.0 | Φ0.3~Φ3.0 |
| Max Drill Depth | 400 | 300 |
| Max Pressure of Working water | 140kg/ cm² | 60 kg/cm² |
| Working tank Dimension | 800*450 | 700*480 |
| Max Diameter to Depth Ratio | ≥300 | ≥300 |
| Machine Weight | 900kg | 650kg |
| Maximum Current | 30A | 30A |
| Working material | Steel/aluminum/copper/kinds of conductors | |
| Working fluid | water/lon free water | water/lon free water |
| Maximum Work Speed | 30-60mm(Φ1.0) | 30-60mm(Φ1.0) |
1. Make deep hole from diameter 0.15-3.0mm rapidly
2. Servo motor drive Z axis move rapidly
3. Z axis adopt Taiwan Hiwin linear guideway
4. X,Y,Z axes adopt ball screw
5. Special high pressure water pump from Taiwan
6. Automatic drilling process, depth setting drilling, blind hole drilling
function
7. Operation combined by one key function, Z axis CNC control(optional)
Micro Hole Drilling EDM Machine Workshop
