Tire Mould EDM Sinking Machine

Main Unit Features:
1.Designed for radial segmented parting tire molds.
2.The worktable equipped with encoders can ensure positioning accuracy.
3.The worktable can be rotated and tilted to meet the machining requirement for side patterns of radial parting mold and stamping steel plate.
4.Z axis permits tilting for efficient residue exhaust, while upgrading machining stability and efficiency.
5.Micrometer adjustment on X1 and Y axis for ease of electrode setup.
6.The work head can be moved to the side for convenient mold setup.

Features of CNC Control:

1. The control employs INTEL PENTIUM industrial grade master board.

2. 15 TFT LCD monitor.

3. Conversational operation interface.

4. Automatic table type editing for 10-step machining programs creation.

5. Tungsten steel, extra hard and special material eroding circuit.

6. Graphite machining circuit is ideal for machining bronze and graphite.

7. MPG handwheel for micrometric positioning adjustment.(Optional)

8. Unlimited machining programs fully meet flexible machining requirements such as various angles and patterns of tire molds.

9. Relative coordinate, absolute coordinate and constant indexing function make the machine suitable for machining any tire mold.

10. Random home position function. Machining home position can be set as desired.

11. Specially designed protection function to prevent electrode from bumping against the mold.

12. Indexing accuracy 0.001°.
    13.Allows for inconsistent indexing machining.
