Mechanical Double Rope grab bucket for lifting
Technical Features
Mechanical Double Rope grab bucket with double rope is a in a variety of harsh environments in sand, coal, mineral powder and bulk chemical fertilizer for loading and unloading bulk effective tool. With simple structure, opening and closing mechanism is novel, convenient operation, can accurately complete in various states open close.
Grab by the use of 3D virtual design, and the ANSYS software for strength analysis and verification, the weight distribution more reasonable and longer service life.
Suitable for small double drum grab crane handling various types of bulk cargo, general double rope grab lifting weight is not greater than 16t. Grab the upper beam is provided with lifting lugs, and hoisting rope shackle connected directly.
Specification
|
Type&Size |
Grab volume (m3) |
Bulk density(t/m3) |
Dead weight (t)(Rate) |
Dimensions (mm) |
Diameter of Sheave (mm) |
Use height(m) |
Dimaeter of wirerope(mm) |
Crane lifting weight (t) |
||||
|
A |
B |
C |
D |
E |
||||||||
|
BS3[1.2]1.3A |
1.2(300) |
1.5 |
1.4(4) |
1900 |
2537 |
2488 |
2841 |
1200 |
Ø400 |
9 |
Ø17.5 |
3 |
|
BS3[1.6]1.4A |
1.6(300) |
1 |
1.4(4) |
2100 |
2631 |
2559 |
3040 |
1300 |
Ø400 |
9.5 |
Ø17.5 |
3 |
|
BS5[1.5]2A |
1.5(350) |
2 |
2(3) |
2100 |
2549 |
2562 |
3030 |
1260 |
Ø445 |
8.5 |
Ø19.5 |
5 |
|
2(4) |
9.8 |
|||||||||||
|
BS5[2]2A |
2(350) |
1.5 |
2(4) |
2100 |
2778 |
2818 |
3248 |
1400 |
Ø445 |
10 |
Ø19.5 |
5 |
|
BS5[2.5]2A |
2.5(350) |
1.2 |
2(3) |
2100 |
2787 |
2715 |
3091 |
1600 |
Ø445 |
8.5 |
Ø19.5 |
5 |
|
BS5[3]2A |
3(400) |
1 |
2(3) |
2300 |
3141 |
2915 |
3337 |
1650 |
Ø445 |
9 |
Ø19.5 |
5 |
|
BS8[2.6]3.2A |
2.6(300) |
1.8 |
2.6(4) |
2300 |
3038 |
3257 |
3736 |
1800 |
Ø560 |
11 |
Ø26 |
8 |
|
BS8[3]3.3A |
3(300) |
1.5 |
3.3(4) |
2380 |
3118 |
3287 |
3786 |
1900 |
Ø560 |
11.5 |
Ø26 |
8 |
|
BS8[3.8]3.5A |
3.8(300) |
1.2 |
3.5(4) |
2550 |
3536 |
3286 |
3733 |
2000 |
Ø560 |
12 |
Ø26 |
8 |
|
BS8[4.5]3.8A |
4.5(300) |
0.9 |
3.8(3) |
2500 |
3505 |
3503 |
3975 |
2300 |
Ø560 |
12 |
Ø26 |
8 |
|
BS10[3]4A |
3(300) |
2 |
4(4) |
2380 |
3118 |
3287 |
3786 |
1900 |
Ø560 |
11.5 |
Ø28 |
10 |
|
BS10[5]4A |
5(350) |
1.2 |
4(4) |
2580 |
3605 |
3503 |
3975 |
2400 |
Ø560 |
12 |
Ø28 |
10 |
|
BS10[6]4A |
6(400) |
1 |
4(4) |
2700 |
3714 |
3733 |
4265 |
2500 |
Ø560 |
12.5 |
Ø28 |
10 |
|
BS16[3.6]6A |
3.6(300) |
2.8 |
6(5) |
2500 |
3313 |
3810 |
4206 |
2100 |
Ø720 |
13.5 |
Ø32 |
16 |
|
BS16[4]6A |
4(350) |
2.5 |
6(5) |
2500 |
3313 |
3810 |
4206 |
2200 |
Ø720 |
13.5 |
Ø32 |
16 |
|
BS16[6]6A |
6(350) |
1.6 |
6(4) |
2900 |
3800 |
4249 |
4612 |
2400 |
Ø720 |
13.5 |
Ø32 |
16 |
|
BS16[10]6A |
10(400) |
1 |
6 (3) |
3200 |
4000 |
3938 |
4673 |
2500 |
Ø650 |
12 |
Ø28 |
16 |
Packaging Details: Mechanical part packing by plastic bag, electric parts by wooden box or standard exporting packing/Electrical and other parts are packaged by high quality plywood crates, main beams are packaged by Plastic Film.
Delivery Detail: Within 30 days after received your advance payment.
About us
ZDPM is one of the leading manufacturers of 60,000 square feet with dedicated, licensed and certificated staff, product range such as marine cranes, grabs, container spreaders, port cranes, crane clamps, hoppers and other spare parts.
ZDPM have got the SGS, CCS, BV, CE, ABS, ISO9000: 2008, ISO14001: 2004, OHSAS and other certifications, also accept third party inspection, such as SGS Factory test etc.
Auto CAD, 3DMax, Math CAD, Solid Works, ANSYS and SAP2000 Advanced.
16 months warranty after installation and commissioning unless the human damage factors.
24/7/365 day service, 2 years spare parts provided for better maintenance.
ZDPM committed not only supply high quality, on time delivery, reliable after sales service, but also offer the most competitive prices. Welcome to visit our factory!
Product Show
