High Quality container Spreader for Sale
Technical Features
The crane must be supplied with the telescopic spreader.
All drives for spreader are electro-mechanical.
A length of the spreader should be regulated according to the transportation of 20 - 40 feet container.
Floating twistlocks should be used for container fixation in the spreader. Separation and grip drives should have electrical supply.
The spreader should be hanged on the swing frame of the crane.
Spreader twistlocks must provide the possibility of unevenly placed containers handling.
The spreader should have small foothold in order to handle the containers covered by snow.
The blocking device system aimed to preclude the possibility of spreader lifting after the malfunction of twistlocks should be installed on the spreader. This blocking device system should also preclude the twistlock operation when the container is lifted.
Signaling devices (lamps) confirming the twist lock operation should be installed on the spreader.
Specification
|
Rated load |
Adjustable range |
Effective length |
Dimensions(mm) |
Grab volume (Dome) |
||||
|
(t) |
(m) |
L1(m) |
A |
B |
C |
L |
H |
Kg |
|
2 |
2-3 |
3 |
80 |
150 |
570 |
3184 |
180 |
142 |
|
3.2 |
3-5 |
5 |
100 |
220 |
828 |
5200 |
300 |
400 |
|
5 |
3-5 |
5 |
100 |
220 |
935 |
5300 |
300 |
517 |
|
8 |
4-6 |
6 |
160 |
360 |
1140 |
6312 |
340 |
978 |
|
10 |
4-6 |
6 |
160 |
360 |
1140 |
6312 |
340 |
1136 |
|
12.5 |
4-6 |
6 |
180 |
400 |
1320 |
6320 |
370 |
1381 |
|
16 |
6-8 |
8 |
180 |
430 |
1370 |
8320 |
450 |
2323 |
|
20 |
6-8 |
8 |
180 |
430 |
1485 |
8360 |
450 |
2635 |
|
25 |
6-8 |
8 |
200 |
500 |
1755 |
8500 |
530 |
3107 |
|
32 |
8-10 |
10 |
220 |
600 |
2135 |
10640 |
650 |
4710 |
|
40 |
8-10 |
10 |
220 |
600 |
3165 |
10640 |
650 |
5433 |
Delivery Detail: Within 30 days after received your advance payment.
About us
ZDPM is one of the leading manufacturers of 60,000 square feet with dedicated, licensed and certificated staff, product range such as marine cranes, grabs, container spreaders, port cranes, crane clamps, hoppers and other spare parts.
ZDPM have got the SGS, CCS, BV, CE, ABS, ISO9000: 2008, ISO14001: 2004, OHSAS and other certifications, also accept third party inspection, such as SGS Factory test etc.
Auto CAD, 3DMax, Math CAD, Solid Works, ANSYS and SAP2000 Advanced.
16 months warranty after installation and commissioning unless the human damage factors.
24/7/365 day service, 2 years spare parts provided for better maintenance.
ZDPM committed not only supply high quality, on time delivery, reliable after sales service, but also offer the most competitive prices. Welcome to visit our factory!
Product Show
FAQ
Pls kindly send us your detailed specifications as follow if you are interested in our hoppers.
1. What kind of the hopper you need?
2. What kind of the material the hopper loading:
For example: Grain, Sulfur, Chemical fertilizer?
3. Crane Tone (The tonne of the crane )or what kind of the crane that the hopper working with?
4. If possible could you show us a pic or send us your tech drawing for our info?
5. Do you have any requirements of the exist valve?
6. What's the height of the hopper?
7. What's the working environment?
8. Your nearest port: (_______) We quote C&F price need the port. FOB price please note FOB
