4 in 1 Aseptic Juice Filling Machine Automatic Hot Filling

4 in 1 Aseptic Juice Filling Machine Automatic Hot Filling Machine

Quick Detail:

1. Completely juice process line
2. Production capacity: 4000-20000bph
3. Bottle size: 250-2000ml
4. Rinsing, washing, filling, capping machine 4-1
5. Material: SS304
6. Warranty: 1year free

Completely juice process line

Description:

Main features:

• Juice production line specially designed for juice bottle filling and sealing.
• All new design. The new technology of this machine is designed by our factory, which get the technical patent.
• A highly automated juice production line. The operation cycle, from cup feeding, filling, sealing to product outfeed are fully automatically performed. It's a necessity in mass production line!
• Suitable Containers : Plastic cup / Plastic Bowl / Plastic Box / paper cup
• Suitable Packing Materials : Nylon Film/ Metalized Film/ Aluminum Film
• Available Products : Drinking water / Soybean Milk/ Milk Tea / Juice / Yogurt / All kinds of Liquids

Application:

This Juice filling machine adopts German technology, combined with years of experience in the Company after the development of new products. RXG series hot juice filling machine is the standard 3-in-1 monoblock. But to the special production condition, another sanitizer rinsing could be added, that is 4-in-1 monoblock. The system has fully considered the beverage’s characteristics (such as the frothing of the tea drink and mixed juice) and the technical requirement of the hot filling.4 in 1 Washing, Filling (Pulp), Filling (juice), capping machine. Or Washing (disinfectant), Washing (pure water), Filling, Capping machine. Custom machines according to different requirements for the user.

Specifications:

Completely juice process line

Washing machine

Water spray style inject washing design, more save water consumption & more clean

304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing

304 stainless steel washing pumps

Filling machine

Gravity filling nozzle, easy & steadily

Filling volume adjustable in fine rank, same liquid level after filling

All 316L stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean

No bottle no filling

In-build bottle tray device, avoid bottle crash

CIP clean side-way pipeline

Capping machine

Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping

All 304stainless steel construction

No bottle no capping,

Automatic stop when lack of bottle

Automatic caps arranging and feeding, lack of caps automatic feeding
