Railway Fish Bolt with Nut and Washer
- Payment Type:
- T/T, L/C
- Incoterm:
- FOB
- Min. Order:
- 3000 Piece/Pieces
- Min. Order:
- 3000 Piece/Pieces
- Delivery Time:
- 20 Days
- Transportation:
- Ocean
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China |
|---|---|
| Productivity: | 600, 000PCS/Month |
| Supply Ability: | 600, 000PCS/Month |
| Payment Type: | T/T,L/C |
| Incoterm: | FOB |
| Transportation: | Ocean |
Product Description
Product Description
Standard: ASTM, DIN, BSW, GB, JIS, UIC, Russian or drawings from customers.
Materail: Carbon steel or stainless steel, Q195, Q235, 35#, 45#, 35CrMo, 42CrMo, 40Cr etc.
Surface Finish: plain (oiled), hot dip galvanized, white zink plated, yellow zink plated, black, dacromet, geomet or others specified by the customers.
Materail: Carbon steel or stainless steel, Q195, Q235, 35#, 45#, 35CrMo, 42CrMo, 40Cr etc.
Surface Finish: plain (oiled), hot dip galvanized, white zink plated, yellow zink plated, black, dacromet, geomet or others specified by the customers.
| D | L | I | Threads Per Inch |
| Nom. Dia. Over Thread | Length Under Head | Min. Thread Length | |
| 7/8 | Under 7",in steps of 1/4" From 7" to 10" in steps of 1/2" | 2" | 9 |
| 1 | 2-1/4" | 8 | |
| 1-1/8 | 2-1/2" | 7 | |
| Additional Sizes Now in Use But Not Recommended for New Designs | |||
| 13/16 | Same as above | 1-7/8" | 10 |
| 15/16 | 2-7/8" | 9 | |
| 1-1/16 | 2-3/8" | 8 | |
|
Note: All dimensions given in inches. Tolerances: Length (L) ± 1/8", Neck (O and R1) ± 0.0313", Head (A and H) ± 0.0625", R2 ±0.0175" In ordering bolts, specify the nominal dia |
|||
