LSZH LSZH for electric cable compound
- Delivery Time:
- 7 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China (Mainland) |
|---|
Product Description
Product Description
Specifications 1. LSZH electric cable compound
2. Perfect electric performance
3. Good flame-retardant
4. Good flexibility
MG80015 (86±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound MG80015-3 (80±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound MG80015-5 (70±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound Flame-retardant polyolefin low-Smoke non-halogen thermoplastic elastomer compound is based on polyolefin, which is mixed with abio-flame -retardant and antioxidant etc. It features soft texture and low smoke density, which is the excellent substitute for soft PVC in soft cable and home electric wires etc.
1.About us In 2001,we began to develop the environmental conscientious polymer compound for our cable and wire customers.Now we are accepted as a lead manufacturer of flexible vinyl compound and LSHF compound in China mainland market.We formulate more than 20,000 tons Rosh complaisant compund each year for demostics and oversea market. 2.Products application Apart from being widely used in the cable and wire industry, Mega polymer compounds have a variety of other applications in the market, such as automotive, tool handle, toys, medical tubing, and other industrial and residential applications.
For each application, our engineers from Mega will design particular formulation and process to meet each requirement of the compound including hardness, color and cost. They will co_operate closely with customers to make sure that each secification of the compound to be met. 3.Expertise Vinyl resin is an extremely versatile thermoplastic polymer suitable for a wide range of applications. Vinyl resin attains its usefulness through various additives that allow it to be used in a multitude of markets and products – everything from automotive parts to medical tubing, from building and construction to children's toys. Vinyl is very durable, relatively cost efficient and meets stringent regulations and requirements mandated by many industries 4.Laboratory
Mega highskilled staff and wellequipped laboratory ensure the compound be tested both on design stage and process spot , so that to keep the products consistently meet each customer's unique requirements. Now we can undergo such testing items: tensile strength, elongation, gravity, air oven aging, pad volume resistivity , heat stability, flame-retardant (Oxygen Index), melt flow analysis, air oven aging, color meter, water resistance, oil resistance. Mega also uses atomic absorption spectrometry (AA) and X-Ray spectrometry to analyze environmental sensitive elements of raw material , so as to ensure they are RoSH compliant. 5.Industry Listings and Certifications:
Product Safety: UL, CSA, VDE & CCC
Quality Management System: ISO9001-2004
Environment Management: ISO14001-2004 6.Remark If you want to get more information about the products or establish business relationship with us, please feel free to contact us. Tel: 86-512-65275752 / 86-Fax: 86-512-65277403 Phone:+86-13404235070 Homepage:www.megaplastics.com 7.Green compliancy Mega is extremely conscientious about providing customers with accurate information about our products and processes relating to environmental compliancy and established industry specifications and standards. We are pride on working with each customer to address their specific product and market needs. We will remain committed to finding new ways to formulate traditional and new compounds with minimal or no defined hazardous ingredients, as well as offer more eco-friendly alternatives whenever possible. Compliance will continue to be a Mega core competency as new research and regulations evolve around the world for vinyl and other plastics. 8.Mega office
8.Mega workshop
9.Variety Colours
10.Laboratory
11.CERTIFICATION
2. Perfect electric performance
3. Good flame-retardant
4. Good flexibility
MG80015 (86±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound MG80015-3 (80±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound MG80015-5 (70±2A) Flame-retardant polyolefin low-Smoke non-halogen elastomer compound Flame-retardant polyolefin low-Smoke non-halogen thermoplastic elastomer compound is based on polyolefin, which is mixed with abio-flame -retardant and antioxidant etc. It features soft texture and low smoke density, which is the excellent substitute for soft PVC in soft cable and home electric wires etc.
Test Items | Unit | Typical Value | ||
MG80015 | MG80015-3 | MG80015-5 | ||
Density (23°C) | g/cm3 | 1.36 | ||
Hardness (Shore A) | A | 86 | ||
Tensile strength | MPa | 11.3 | ||
Elongation at break | % | 290 | ||
Oven aging condition | °C x h | 100 x 168 | ||
Tensile strength after aging | 12.4 | 12.4 | 13.1 | |
Variable rate of Tensile strength | % | +9.7 | +14.8 | +10 |
Elongation at break after aging | 260 | 290 | 265 | |
Variable rate of Elongation at break | % | -10.3 | -17.1 | -14.5 |
Low temperature brittleness | °C | -25 pass | -25 pass | -25 pass |
20°C Volume resistivity | Ω·cm | 6.2x101 | 5.9x1014 | 8.6x1014 |
Dielectric strength | MV/m | 27 | 27 | 28 |
Oxygen index | % | 34 | 31 | 30 |
HC1 Acid gas emission | mg/g | 0 | 0 | 0 |
pH | 6.1 | 6.0 | 6.3 | |
Conductivity | μs/mm | 0.4 | 0.5 | 0.3 |
Dm(1.0mm) Smoke density | flame | 57 | 55 | 42 |
non-flame | 162 | 151 | 147 | |
For each application, our engineers from Mega will design particular formulation and process to meet each requirement of the compound including hardness, color and cost. They will co_operate closely with customers to make sure that each secification of the compound to be met. 3.Expertise Vinyl resin is an extremely versatile thermoplastic polymer suitable for a wide range of applications. Vinyl resin attains its usefulness through various additives that allow it to be used in a multitude of markets and products – everything from automotive parts to medical tubing, from building and construction to children's toys. Vinyl is very durable, relatively cost efficient and meets stringent regulations and requirements mandated by many industries 4.Laboratory
Mega highskilled staff and wellequipped laboratory ensure the compound be tested both on design stage and process spot , so that to keep the products consistently meet each customer's unique requirements. Now we can undergo such testing items: tensile strength, elongation, gravity, air oven aging, pad volume resistivity , heat stability, flame-retardant (Oxygen Index), melt flow analysis, air oven aging, color meter, water resistance, oil resistance. Mega also uses atomic absorption spectrometry (AA) and X-Ray spectrometry to analyze environmental sensitive elements of raw material , so as to ensure they are RoSH compliant. 5.Industry Listings and Certifications:
Product Safety: UL, CSA, VDE & CCC
Quality Management System: ISO9001-2004
Environment Management: ISO14001-2004 6.Remark If you want to get more information about the products or establish business relationship with us, please feel free to contact us. Tel: 86-512-65275752 / 86-Fax: 86-512-65277403 Phone:+86-13404235070 Homepage:www.megaplastics.com 7.Green compliancy Mega is extremely conscientious about providing customers with accurate information about our products and processes relating to environmental compliancy and established industry specifications and standards. We are pride on working with each customer to address their specific product and market needs. We will remain committed to finding new ways to formulate traditional and new compounds with minimal or no defined hazardous ingredients, as well as offer more eco-friendly alternatives whenever possible. Compliance will continue to be a Mega core competency as new research and regulations evolve around the world for vinyl and other plastics. 8.Mega office
8.Mega workshop 9.Variety Colours 10.Laboratory 11.CERTIFICATION
