Flame-retardant Halogen free fire-retardant polyolefin compound for injection

Specifications 1. Perfect electric performance

2. Good flame-retardant proprety

3. Easily processed

4. Eco-friendly

5. Long term service

        Introduction:
    Flame-retardant polyolefin low-Smoke non-halogen for injection moulding compounds is based on polyolefin resin, which is mixed with non-halogen flame retardant, and other process agent, to knead, plastify, and then extrude into pellets. It has excellent mechanical properties, flame-retardant property and processing properties. It can be applied in kinds of branch cable and connector assembly.     MG80012A-1(90A) Flame-retardant polyolefin low-Smoke non-halogen injection moulding compound     MG80012A-2(85A) Flame-retardant polyolefin low-Smoke non-halogen injection moulding compound     MG80012A-3(80A) Flame-retardant polyolefin low-Smoke non-halogen injection moulding compound

Test Items	Unit	Typical Value
		MG80012A-1	MG80012A-2	MG80012A-3
Density(23°C)	g/cm3	1.25	1.26	1.2
Hardness  (Shore A)	A	90	85	80
Tensile strength	MPa	12.3	11.7	10.2
Elongation at break	%	190	180	170
low temperature impact Brittleness	°C	-25	-25	-25
20°C Volume resistivity	Ω·cm	5.1x1012	1.5x1013	5.6x1013
Dielectric strength	MV/m	28	27	26
Oxygen index	%	31	31	30
Acid gas emission	mg/g	0	0	0
pH		6.0	6.3	6.1
Conductivity	μs/mm	0.4	0.6	0.9
Dm(1.0mm) Smoke density	Flame	60	59	64
	Non-Flame	170	161	168

♦ Variety Colours ♦ Workshop show ♦ Company Certifications: ◊ ISO 9001:2008 ◊ ISO 14001:2004 ◊ Certification of UL
