Flexible LS0H elastic compound for wire/cable

Specifications 1. Eco-friendly

2. Perfect electric performance

3. Good flame-retardant

4. Good flexibility

5. Toxic gas emission free

      MG80015 (86±2A)     Flame-retardant polyolefin low-Smoke non-halogen elastomer compound     MG80015-3 (80±2A)   Flame-retardant polyolefin low-Smoke non-halogen elastomer compound     MG80015-5 (70±2A)   Flame-retardant polyolefin low-Smoke non-halogen elastomer compound       Flame-retardant polyolefin low-Smoke non-halogen thermoplastic elastomer compound is based on polyolefin, which is mixed with abio-flame -retardant and antioxidant etc. It features soft texture and low smoke density, which is the excellent substitute for soft PVC in soft cable and home electric wires etc.

Test Items	Unit	Typical Value
		MG80015	MG80015-3	MG80015-5
Density (23°C)	g/cm3	1.36
Hardness (Shore A)	A	86
Tensile strength	MPa	11.3
Elongation at break	%	290
Oven aging condition	°C x h	100 x 168
Tensile strength after aging		12.4	12.4	13.1
Variable rate of Tensile strength	%	+9.7	+14.8	+10
Elongation at break after aging		260	290	265
Variable rate of Elongation at break	%	-10.3	-17.1	-14.5
Low temperature brittleness	°C	-25 pass	-25 pass	-25 pass
20°C Volume resistivity	Ω·cm	6.2x101	5.9x1014	8.6x1014
Dielectric strength	MV/m	27	27	28
Oxygen index	%	34	31	30
HC1 Acid gas emission	mg/g	0	0	0
pH		6.1	6.0	6.3
Conductivity	μs/mm	0.4	0.5	0.3
Dm(1.0mm) Smoke density	flame	57	55	42
	non-flame	162	151	147

  ♦ Variety Colours ♦ Workshop show ♦ Company Certifications: ◊ ISO 9001:2008 ◊ ISO 14001:2004 ◊ Certification of UL
